Operation
47
3. Pull up the shallow water lever (if
equipped).
4. Hold the rear of the top cowling with one
hand and tilt the engine up fully.
5. Push the tilt support knob into the clamp
bracket. Or the tilt support bar will turn to
the lock position automatically.
CAUTION:
ECM01640
Do not use the tilt support lever or knob
when trailering the boat. The outboard
motor could shake loose from the tilt sup-
port and fall. If the motor cannot be trail-
ered in the normal running position, use
an additional support device to secure it
in the tilt position. For more detailed in-
formation, see page 55.
EMU32722
Procedure for tilting up (power tilt
models)
1. Place the remote control lever / gear
shift lever in neutral.
2. Press the power tilt switch “” (up) until
the outboard motor has tilted up com-
pletely.
ZMU05548
ZMU05528
ZMU05533
N
✩✮✴✬✤✥✤✲✣ ✧✪
