Operation
49
3. Slowly tilt the engine down.
EMU33120
Procedure for tilting down (power tilt
models)
1. Push the power tilt switch “” (up) until
the outboard motor is supported by the
tilt rod and the tilt support knob becomes
free.
2. Pull out the tilt support knob.
3. Push the power tilt switch “” (down) to
lower the outboard motor to the desired
position.
EMU28060
Cruising in shallow water
The outboard motor can be tilted up partially
to allow operation in shallow water.
EMU28071
Cruising in shallow water (manual tilt
models)
WARNING
EWM00710
●
Place the gear shift in neutral before us-
ZMU05528
ZMU02825
DN
ZMU01936
UP
DN
ZMU05581
DN
DN
ZMU04901
✩✮✴✬✤✥✤✲✣ ✧✬
©2019 Yamaha Motor Corporation, U.S.A.
