5-28
VOLTAGE METER
The voltage meter provides info
rmation about the charging cond
ition of the battery.
VOLTAGE METER APPLICATIONS
VOLTAGE METER DIMENSIONS
WIRING THE VO
LTAGE METER
Ref. No.
Descri
ption
Part
No.
Applicable mod
el
1
DC 12 volts power supply
Black panel
6Y7-83503-00
All electrical start models
2
DC 12 volts power supply
White panel
6Y7-83503-10
12
60 (2.36)
11 (0.43)
46.6 (1.83)
13.7 (0.54)
52 (2.05)
mm (in.)
Y
B
B
L
Battery
IG switch
V
oltage meter
Batt.+12V
Y
B
Lamp switch
L
145
147
