6-6
OPTIONAL EQUIPMENTS
SPEED SENSOR KIT
Uses to pick up the pitot tube pressure for water speed. For installation and connection, see the
instruction in the kit.
The speed sensor kit may include in the rigging kit.
COOLANT PRESSURE SENSOR KIT
Uses to pick up the coolant pressure of engine. For installation and connection, see the instruction
in the kit.
* For F350/F300, standard installed from factory.
Ref. No. Part No. Remarks
1 60V-8A4L1-11 Fuel injected F50-F250, HPDI
2 6AW-8A4L1-01
F350/F300, additional transom pitot tube (688-83556-01) and pressure
tube (688-83557-00) required.
Ref. No. Part No. Remarks
1 60V-8A4L0-11 Fuel injected F50-F115, HPDI
2 69J-8A4L0-11 F150-F250
1
2
1
2
