WIRING DIAGRAMS
GROMMET DESCRIPTION
* If the optional equipment will be installed, cut out the surface skin of rigging grommet on the prescribed posi-
tion.
2-STROKE V4 OIL INJECTION
2-STROKE V6 (2.6L) OIL INJECTION
2-STROKE V6 (3.1L & 3.3L)
Gauge harness &
Remote oil tank lead
10-pin main harness
Remote oil hose
Fuel hose
Throttle cable
Coolant press. tube (OP)
Coolant temp. lead (OP)
Shift cable
Battery cable
Speed tube
Shift cable
Throttle cable
10-pin main harness
Gauge harness
Remote oil tank lead
Battery cable
Remote oil hose
Fuel hose
Speed tube
Isolator cable (OP)
Coolant press. tube and/or
Coolant temp. lead (OP)
Shift cable
Throttle cable
Remote oil tank lead
Battery cable
Fuel hose
Speed tube
Isolator cable (OP)
Remote oil hose
10-pin main harness
Gauge harness
Coolant press. tube and/or
Coolant temp. lead (OP)
