Maintenance and care
91
(3) Install the spark plug, and then tighten it
to the specified torque.
(4) Install the spark plug cap.
NOTE:
● Wipe off any water on the spark plug or in-
side the spark plug cap before installing the
cap. Push the spark plug cap down until it is
securely installed.
● If a torque wrench is not available when you
are installing a spark plug, a good estimate
of the correct torque is 1/4 turn to 1/2 turn
past finger tight using the spark plug
wrench included in the tool kit. Have the
spark plug adjusted to the correct torque
with a torque wrench as soon as possible.
WARNING
EWJ00350
Be careful not to damage the insulator
when removing or installing a spark plug.
A damaged insulator could allow sparks to
escape, which could result in a fire or ex-
plosion.
(5) Install the air filter element in the air filter
case, and then install the air filter case
cover.
EJU34433
Lubrication points
To keep moving parts sliding or rotating
smoothly, coat them with water-resistant
grease.
● Throttle cable (throttle body end)
● Throttle bodies (throttle cable pulley, throt-
tle cam, and return spring)
● Throttle cable (handlebar end)
Loosen the adjuster and disconnect the
outer cable from the bracket. Spray a rust
inhibitor into the outer cable. Connect the
outer cable, and then adjust the throttle ca-
ble free play. (See page 88 for adjustment
procedures.)
● Steering cable (handlebar end)
Spark plug tightening torque:
12.5 Nm (9.2 ft-lb) (1.27 kgf-m)
Recommended water-resistant grease:
Yamaha Marine Grease/Yamaha
Grease A
1 Adjuster
UF1X12E0.book Page 91 Thursday, June 14, 2007 10:24 AM
