Watercraft operation
33
pecially if the Q.S.T.S. selector is not also
in the neutral position.
To shift into forward:
(1) Release the throttle lever and let the en-
gine speed return to idle.
(2) Squeeze the shift lock lever and push the
shift lever forward until it stops in the for-
ward position. The reverse gate will rise
completely and the watercraft will start
moving forward at trolling speed.
EJU31319
Quick Shift Trim System (Q.S.T.S.)
The Q.S.T.S. selector is located at the left
handlebar grip and is operated to change the
vertical angle of the jet thrust nozzle, which
adjusts the trim angle of the watercraft.
1 Shift lever
2 Neutral position
1 Reverse gate
2 Neutral position
1 Neutral indicator “N”
1 Shift lever
2 Shift lock lever
3 Forward position
1 Reverse gate
2 Forward position
