MAINTENANCE
2. Connect the wire leads as shown.
å Forward
∫ To relay
ç To controller and receptacle
∂ Between batteries
When installing batteries:
● Carefully place battery cables
and holddowns making sure that
cables don’t lie across vent caps.
● Always remove the negative (–)
cable to the motor controller first,
and install it last.
Do not overtighten the battery
holddown nuts. Excessive force
will damage the battery casing.
Fuse Replacement
Be sure to use the specified fuse.
Using a wrong fuse can cause
electrical system damage and cre-
ate a fire hazard.
When replacing a fuse be sure the
main switch is turned off to pre-
vent accidental short-circuiting.
å Fuse case
∫ Fuse
