10-1
G19E
SPECIFICATIONS
GENERAL SPECIFICATIONS
Items G19E
Dimensions:
Overall length 93.9 in. (2385 mm)
Overall width 47.2 in. (1200 mm)
Overall height (steering height) 46.9 in. (1190 mm)
Height of floor 11.8 in. (300 mm)
Wheelbase 64.1 in. (1629 mm)
Tread:
Front 34.3 in. (870 mm)
Rear 38.6 in. (980 mm)
Min. ground clearance 3.8 in. (97 mm)
Weight:
Dry weight (without battery) 560 lb (254 kg)
Performance:
Maximum speed 12-15 mph
(19-24 km/h)
Minimum turning radius 113.0 in. (2.8 m)
Seating capacity 2 persons
Hill climbing ability 24˚ (44% grade)
on pavement
TRANSMISSION
Items G19E
Differential/reduction gear:
Differential type Bevel gear
Lubricant/capacity SAE 90 gear oil/
0.32 US qt (0.3 L,
0.26 Imp qt)
BATTERIES
Items G19E
Battery: BCI group GC-2H
RC: minimum 105 min
