LS9-16/LS9-32
10
LAMP (LS9-32 only)
1
4
2
Pin
Signal Name
1
2
3
4
NC
NC
GND
+12V
3
25 430
480
25
220
500
220
500
884
834 2525
Unit（単位）: mm
LS9-16
LS9-32
DIMENSIONS（寸法図）
PIN ASSIGNMENT（ピンアサイン表）
