LS9-16/LS9-32
START-UP SEQUENCE
A1. Start-up mode
Mode Mode Changing Method Description on the Operation
Normal mode
This mode is selected as
default without any special
operation
Checks the hardware at the start-up.
Normal operation starts if there is no error.
If an error is detected, the mode will change to Maintenance mode automatically.
Forced Factory
Preset mode
While holding down the
[SCENE] key and [MIX1]
key, turn on the power.
Executes the Factory Preset operation of the Memory API.
Initializing the Current Memory, Scene, etc.
During the initialization, “Initializing Flash Memory...” will be shown in the top right of the LCD.
After the initialization, the mode will change to Normal mode and normal
operation will start.
Maintenance mode
While holding down the
[SCENE] key, turn on the
power.
The LCD screen will show maintenance menus (refer to “LCD screen
operation specications”).
• INITIALIZE ALL MEMORY
• INITIALIZE CURRENT MEMORY
Refer to “C. About Memory Initialization” (page 192) for the memory
contents to be initialized
During the initialization, the message “Initializing…” will blink on the LCD.
When the initialization is nished, the condition after the initialization will be
indicated as a sound.
• INPUT PORT TRIM
• OUTPUT PORT TRIM
• SLOT OUTPUT TRIM
TRIM adjustment will be indicated as a sound in real time.
• FADER CALIBRATION
• LCD CONTRAST OFFSET CALIBRATION
The mode to adjust individual difference of LCD contrast will be selected if
the RACK[1]-[4] key and RACK[5]-[8] key are pressed simultaneously when
the maintenance menu is displayed.
Refer to the service check program (page 120) for details.
• EXIT
Changes to Normal mode.
Functions restricted in the Maintenance mode
Panel
All the LEDs will be turned off except the “SEL” LEDs during Fader Calibration.
Faders are inoperable (movable, but moving faders does not change values)
except in Fader Calibration operation.
Only the cursor keys, [ENTER] key, [INC]/[DEC] key and parameter wheel are operable.
Communication, USB Storage, Audio
Inoperable
The functions are restricted until the Normal mode is selected by pressing
the EXIT button.
Servicing Diag
mode
Turn on the power while
holding down the 3 buttons
(User Defined Key [1],
[2], [3]) simultaneously.
Starts with the Mac Address written on the Flash ROM.
Receives Diag command through Ethernet and executes Diag procedure.
Panel and LCD indication need respective Diag procedure looping.
It is impossible to change from the Diag mode to another mode. Cycle
the power to leave the Diag mode.
