Using as a Master Keyboard
141
Owner’s Manual
Quick Guide — Advanced Course
Setting up the Master Zones to Split or Layer
This operation lets you easily determine whether the Zones of the selected Master are to be used in a Split or a Layer. The
note range settings for each Zone can be determined by setting the NoteLimitH and NoteLimitL parameters from the NOTE
display ([MASTER] → [EDIT] → Zone selection → [F2] NOTE).
n Zones 1 and 2 are used in the explanations here.
1 In the Master Play mode, press the [JOB] button to enter the Master Job mode.
2 Press the [F1] INIT button to call up the Initialize display.
3 Uncheckmark the box of “All” by using the [DEC/NO] button and checkmark the box of “Zone.”
4 Set the Type to “Split” or “Layer.”
When Type is set to “Split”
Set the UpperCh (MIDI transmit channel of the upper range), LowerCh (MIDI transmit channel of the lower range), and Split
Point (which separates the keyboard into the upper range and lower range).
When Type is set to “Layer”
Set the UpperCh (MIDI transmit channel of Zone 1) and LowerCh (MIDI transmit channel of Zone 2).
5 Press the [ENTER] button. (The display prompts you for confirmation.)
To cancel the Job, press the [DEC/NO] button.
6 Press the [INC/YES] button to execute the Job.
After the Job has been completed, a “Completed” message appears and operation returns to the original display.
Keep in mind that the Job may take a short time to complete, during which an “Executing..” or “Please keep power on” message may be shown.
Never attempt to turn off the power while data is being written to Flash ROM while such a message is displayed. Turning the power off in this state
results in loss of all user data and may cause the system to freeze (due to corruption of data in the Flash ROM). This may also result in the MOTIF
ES being unable to properly start up the next time the power is turned on.
Lower Upper
Split Point
(C3)
Layer (Upper)
Layer (Lower)
To Next Page
