Yamaha MT 10 - Fuse Specifications and Ratings

Specifications
10-3
1
2
3
4
5
6
7
8
9
10
11
12
License plate light:
LED
Meter lighting:
LED
Neutral indicator light:
LED
High beam indicator light:
LED
Turn signal indicator light:
LED
Oil pressure and coolant temperature warning
light:
LED
Engine trouble warning light:
LED
Steering damper and suspension warning
light:
LED
ABS warning light:
LED
Cruise control “SET” indicator light:
LED
Cruise control “ON” indicator light:
LED
Immobilizer system indicator light:
LED
Shift timing indicator light:
LED
Traction control system indicator/warning
light:
LED
Fuse(s):
Main fuse:
50.0 A
Terminal fuse 1:
2.0 A
Headlight fuse:
10.0 A
Brake light fuse:
1.0 A
Signaling system fuse:
7.5 A
Ignition fuse:
15.0 A
Radiator fan motor fuse:
15.0 A
Sub radiator fan motor fuse:
10.0 A
Hazard fuse:
7.5 A
ABS ECU fuse:
7.5 A
Fuel injection system fuse:
15.0 A
SCU fuse:
7.5 A
ABS motor fuse:
30.0 A
ABS solenoid fuse:
10.0 A
Cruise control fuse:
1.0 A
Backup fuse:
7.5 A
Electronic throttle valve fuse:
7.5 A
