Yamaha MT09 2020 User Manual

Instrument and control functions
5-24
1
2
3
4
5
6
7
8
9
10
11
12
With the engine turned off:
1. Move the sidestand down.
2. Set engine stop switch to run position.
3. Turn main switch to on position.
4. Shift transmission into neutral.
5. Push the start switch.
Does the engine start?
With the engine still running:
6. Move the sidestand up.
7. Pull the clutch lever.
8. Shift transmission into gear.
9. Move the sidestand down.
Does the engine stall?
After the engine has stalled:
10. Move the sidestand up.
11. Pull the clutch lever.
12. Push the start switch.
Does the engine start?
The system is OK. The motorcycle can be ridden.
YES NO
YES NO
YES NO
The neutral switch may not be working.
The motorcycle should not be ridden until
checked by a Yamaha dealer.
The clutch switch may not be working.
The motorcycle should not be ridden until
checked by a Yamaha dealer.
The sidestand switch may not be working.
The motorcycle should not be ridden until
checked by a Yamaha dealer.
If a malfunction is found, have the vehicle
inspected before riding.
WARNING
BS2-9-13.book 24 ページ ２０１９年７月２５日 木曜日 午前１１時１分

Yamaha MT09 2020 Specifications

General

Bore x Stroke	78.0 mm x 59.1 mm
Compression Ratio	11.5:1
Fuel System	Fuel Injection
Ignition System	TCI: Transistor Controlled Ignition
Final Drive	Chain
Front Suspension	Telescopic fork
Front Tire	120/70ZR17M/C (58W)
Rear Tire	180/55ZR17M/C (73W)
Overall Width	815 mm
Fuel Capacity	14 L
Wet Weight	193 kg
Starter System	Electric
Frame	Diamond
Ground Clearance	135 mm
Engine Type	Liquid-cooled, 4-stroke, DOHC, 3-cylinder
Transmission	6-speed
Rear Suspension	Swingarm
Front Brakes	Hydraulic dual disc
Rear Brakes	Hydraulic disc
Overall Length	2075 mm
Overall Height	1120 mm
Wheelbase	1440 mm
Maximum Power	115 PS (84.6 kW) @ 10, 000 rpm
Maximum Torque	87.5 Nm (8.9 kg-m) @ 8, 500 rpm
