Yamaha MT4X User Manual

Appendix 46
User’s Guide
Specifications
Model
4-track/4-channel one direction recording and playback cassette recorder with mixer
Tape Transport
Tape Type C-46 ~ 90 cassette tapes CrO2 - Type II (Bias: HIGH; EQ 70 µ s)
Track Configuration 4-track/4-channel one direction recording and playback
Heads 4-track Hard Permalloy record/play head × 1
4-track ferrite erase head × 1
Motor DC servo motor × 1
Tape Speed 9.5 cm/sec , 4.8 cm/sec
Pitch Control Approximately ± 10%
Wow & Flutter 0.1% WRMS (9.5 cm/sec)
Electrical Specifications
Input connectors MIC/LINE × 4
AUX RETURN L/MONO, R × 2
Output connectors AUX SEND × 2
STEREO OUT L, R × 1
MONITOR OUT L, R × 1
TAPE OUT × 4
PHONES L, R × 1
Connectors
MIC/LINE Input impedance 10 k Ω
Nominal input level -10 dB to -50 dB (input fader nominal)
Minimum input level -56 dB (GAIN control MAX, input fader maximum)
Maximum input level +10 dB (GAIN control MIN, headroom margin)
AUX RETURN L/R 1, 2 Input impedance 10 k Ω
Nominal input level -10 dB (AUX RETURN - LEVEL control nominal)
Minimum input level -16 dB (AUX RETURN - LEVEL control maximum)
STEREO OUT L, R Output impedance 1 k Ω
Nominal load impedance 10 k Ω or more
Nominal output level -10 dB (at 10 k Ω load)
AUX SEND 1, 2 Output impedance 1 k Ω
Nominal load impedance 10 k Ω or more
Nominal output level -10 dB (at 10 k Ω load)
MONITOR OUT L, R Output impedance 1 k Ω
Nominal load impedance 10 k Ω or more
Nominal output level -10 dB (at 10 k Ω load)
TAPE OUT 1, 2, 3,
SYNC/4
Output impedance 1 k Ω
Nominal load impedance 10 k Ω or more
Nominal output level -10 dB (at 10 k Ω load)
PHONES (stereo) Nominal load impedance 8 to 40 Ω
Maximum output level 45mw + 45mw (at 40 Ω load)
Mixer
Frequency response (at nominal input and output)
20 Hz to 20 kHz +1 dB / -3 dB MIC IN - STEREO OUT
LINE IN - STEREO OUT
LINE IN - PHONES OUT
