46 En
Playback
You can display the audio and video information of the
current input signal.
1 Press
5
AMP and then press
M
MENU on
the remote control.
The top “SET MENU” display appears in the OSD.
2 Press
8
n repeatedly to select “SIGNAL
INFO” and then press
8
ENTER.
The audio information about the input source appears
in the OSD.
3 Press
8
l / h to toggle between the audio
and video information displays.
4 Press
M
MENU on the remote control again
to exit from “SET MENU”.
■ Audio information
“–––” appears when this unit cannot display the corresponding
information.
■ Video information
“–––” appears when this unit cannot display the corresponding
information.
HDMI error and message
Displaying the input source
information
Information Descriptions
FORMAT
Signal format. When this unit cannot detect a
digital signal, it automatically switches to
analog input.
SAMPLING
The number of samples per second taken from
a continuous signal to make a discrete signal.
CHANNEL
The number of source channels in the input
signal (front/surround/LFE). For example, a
multi-channel soundtrack with 3 front
channels, 2 surround channels and LFE, is
displayed as “3/2/0.1”.
BITRATE
The number of bits passing a given point per
second.
FLAG
Flag data encoded in DTS, Dolby Digital, or
PCM signals that cue this unit to automatically
switch decoders (“Surround EX”, etc.).
SET MENU
.;AUTO SETUP
;MANUAL SETUP
.A;SIGNAL INFO
[ ]/[ ]:Up/Down
[ENTER]:Enter
p
p
Notes
Information Descriptions
HDMI SIGNAL
Type of the source video signals and
the video signals output at the HDMI
OUT jack of this unit.
HDMI RES.
Resolution of the input signal (analog
or HDMI) and the output signal
(HDMI). When input video signals are
composite video or S-video signals,
the input video signals are indicated as
“Composite” or “S-Video”.
ANALOG RES.
Resolution of the analog video signals
output at the COMPONENT VIDEO
MONITOR OUT jacks of this unit.
HDMI ERROR
(HDMI MESSAGE)
Error message for HDMI sources or
connected HDMI devices.
Note
Message Cause
DEVICE OVER
The number of the connected HDMI
components is over the limit.
HDCP ERROR
HDCP authentication failed.
Out of Res.
Out of resolution. The connected monitor is
not compatible with the resolution of the
input video signal.
