Operation
55
ter the throttle lever is moved back to idle.
The stopping distance varies depending on
gross weight, water surface conditions, and
wind direction.
EMU27821
Stopping engine
Before stopping the engine, first let it cool off
for a few minutes at idle or low speed. Stop-
ping the engine immediately after operating
at high speed is not recommended.
EMU27854
Procedure
1. Turn the main switch to “ ” (off).
2. After stopping the engine, disconnect
the fuel line or close the fuel cock if there
is a fuel joint or a fuel cock on the boat.
3. Tighten the air vent screw on the fuel
tank cap (if equipped).
4. Remove the key if the boat will be left un-
attended.
The engine can also be stopped by pulling
the cord and removing the clip from the en-
gine shut-off switch, then turning the main
switch to “ ” (off).
EMU27862
Trimming outboard motor
EWM00740
Excessive trim for the operating condi-
tions (either trim up or trim down) can
cause boat instability and can make
steering the boat more difficult. This in-
creases the possibility of an accident. If
the boat begins to feel unstable or is hard
to steer, slow down and/or readjust the
trim angle.
The trim angle of the outboard motor helps
determine the position of the bow of the boat
in the water. Correct trim angle will help im-
prove performance and fuel economy while
reducing strain on the engine. Correct trim
angle depends upon the combination of
boat, engine, and propeller. Correct trim is
also affected by variables such as the load in
the boat, sea conditions, and running speed.
1. Trim operating angle
