8-6
JC2
MAINTENANCE
å Oil filler hole
Use care not to fill past the MAX
dipstick mark, and be sure no
foreign material enters the
crankcase. Serious engine
damage can result.
After replacing engine oil, check for
oil leaks around the drain plug. If oil
leaks are found, consult a Yamaha
dealer.
Air Filter
To remove the air filter elements:
1. Unlatch the air filter cover clips
and remove cover.
å Air filter cover clips
∫ Air filter cover
2. Lift the air filter and pre-filter out
of the air filter case.
ç Air filter
∂ Pre-filter
Be careful not to drop anything
into the air inlet. Serious engine
damage can result.
To Next Page
