8-7
JC2
Inspection and cleaning:
3. Wash the foam pre-filter in soap
and water. Allow it to dry.
å Soap and water
∫ Foam element
4. Check the filter element. If
damaged or dirty, replace it.
Do not wring out the foam
pre-filter, this could cause it to
tear.
5. To replace the elements,
reverse the above steps.
The pre-filter has a notch on one
side. It will only fit in the case one
way. Serious engine damage can
result from improperly positioned
filter.
Drive Belt
To remove the drive belt:
1. Set the drive select lever halfway
between forward and reverse.
2. Pull up on the drive belt and
push it outward over the edge of
the secondary sheave.
3. Turn the secondary sheave
clockwise and the drive belt will
roll off the sheave.
4. Remove the drive belt from the
primary sheave.
