INTRODUCTION
Part names and functions
Rear panel
a DOCK jack
For connecting an optional Yamaha iPod universal dock (such as
YDS-12) or Bluetooth wireless audio receiver (YBA-10) (☞
p. 33,
☞
p. 35).
b HDMI OUT jack
For connecting an HDMI - compatible TV to output audio/video
signals to (☞
p. 14).
c HDMI1-4 jacks
For connecting external components equipped with HDMI-
compatible outputs to receive audio/video signals from (☞
p. 16).
d ANTENNA jacks
For connecting AM and FM antennas (☞
p. 21).
e COMPONENT VIDEO jacks
For connecting TV that are compatible with component video signals,
using three cables to output video signal (☞
p. 14).
f AV1-5 jacks
For connecting to external devices equipped with audio/video outputs
so that this unit can receive audio/video signals (☞
p. 17, p. 18).
g AV OUT jacks
For outputting audio/video signals received when analog inputs (AV3-
5 or AUDIO1-2) are selected (☞
p. 20).
h AUDIO1-2 jacks
For connecting to external components equipped with analog audio
outputs to input sound into this unit (☞
p. 19).
i MONITOR OUT jack
For connecting a TV capable of receiving video input, and outputting
video signals to it (☞
p. 15).
j AUDIO OUT jacks
For outputting audio signals received when analog inputs such as the
AV5 or AUDIO1-2 jacks are selected (☞
p. 20).
k SUBWOOFER jack
For connecting a subwoofer with a built-in amplifier (☞
p. 12).
l SPEAKER terminals
For connecting the front, center, and surround speakers (☞
p. 12).
m Power cord
For connecting this unit to an AC wall outlet.
ANTENNA
FM GND AM
COMPONENT
VIDEO
P R
P B
Y
OPTICAL
(
TV
)
AV
1
AV
2
AV
3
AV
4
AV
5
AUD
IO 1
AUD
IO 2
COAXIAL
(
CD
)
COAXIAL
OPTICAL
VIDEO
CENTER SURROUND
HDMI 1
(
BD/DVD
)
HDMI 2 HDMI 3
HDMI 4
FRONT
COMPONENT
VIDEO
MONITOR OUT
P R
P B
Y
HDMI
OUT
MONITOR OUT
AV
OUT
SUBWOOFER
AUDIO
OUT
COMPONENT
VIDEO
MONITOR OUT
P R
P B
Y
HDMI
OUT
MONITOR OUT
AV
OUT
SUBWOOFER
ANTENNA
FM
G
ND
C
OMPONENT
VIDEO
P
R
P
B
Y
O
PTI
C
A
L
(
TV
)
AV 1
AV 2
AV 3
AV 4
AV 5
A
U
D
IO
1
A
U
D
IO
2
CO
AXIA
L
(
CD
)
CO
AXIA
L
O
PTI
C
AL
VIDE
O
SURRO
U
H
DMI 1
(
BD
/
DVD
)
H
DMI 2
H
DMI
3
HDMI 4
DOC
K
DOCK
SPEAKERS
ac
fg khj l
d
e i
b
m
Distinguishing the input and output jacks
The area around the audio/video output jacks is
marked in white to prevent connection errors.
Use these jacks to output audio/video signals
to a TV or other external component.
Output jacks
