PERIODIC MAINTENANCE AND ADJUSTMENT
7-39
7
EAU43004
Replacing a turn signal light
bulb
1. Remove the turn signal light unit
by removing the screw.
2. Remove the turn signal light bulb
socket (together with the bulb) by
turning it counterclockwise.
3. Remove the burnt-out bulb by pull-
ing it out.
4. Insert a new bulb into the socket.
5. Install the socket (together with the
bulb) by turning it clockwise.
6. Install the turn signal light unit by
installing the screw.
EAU24313
Replacing the license plate
light bulb
1. Remove the license plate light unit
by removing the screws.
2. Remove the license plate light bulb
socket (together with the bulb) by
pulling it out.
1. Turn signal light unit
2. Screw
1. Turn signal light bulb socket
1. Turn signal light bulb
1. Screw
2. License plate light unit
U1JS11E0.book Page 39 Tuesday, August 2, 2011 3:03 PM
