Maintenance

ADJUSTING THE CHAIN TENSION (See Fig. 30.)

• Stop the motor and disconnect from power supply before setting the chain tension.

• Slightly loosen the chain cover lock knob.

• Turn the chain tensioning knob clockwise to tension the chain.

NOTE: A cold chain is correctly tensioned when there is no slack on the underside of the guide bar,

the chain is snug, and it can be turned by hand without binding.

•Rotatethechaincoverlockknobclockwisetosecure.Retensionthechainwhenevertheflatson

the drive links hang out of the bar groove.

NOTE: During normal saw operation, the temperature of the chain increases. The drive links of a

correctly tensioned warm chain will hang approximately 1/16” (1.3 mm) out of the bar groove.

NOTE: New chains tend to stretch. Check the chain tension frequently and tension as required.

Flats on drive links

Fig. 30-1

Fig. 30-2

CAUTION: A chain tensioned while warm may be too tight

upon cooling. Check the “cold tension” before next use.

≈ 1/16” (1.3 mm)
