YASKAWA CDBR Series User Manual

6 SPECIFICATIONS
53
6.6 MODELS AND CODE NOS. OF BRAKING UNIT
AND BRAKING RESISTOR UNIT
(1) Braking Unit
Inverter
Model Code No.
Voltage HP (kW)
200 to
230 V
20 (15)
CDBR-2015B 72600-R2150B
CDBR-2015C 72600-R2150C
30 (22)
CDBR-2022B 72600-R2220B
CDBR-2022C 72600-R2220C
60 (45)
CDBR-2045B 72600-R2450B
150 (110)
CDBR-2110B 72600-R21100B
380 to
460 V
40 (30)
CDBR-4030B 72600-R4300B
60 (45)
CDBR-4045B 72600-R4450B
120 (90)
CDBR-4090B 72600-R4900B
300 (220)
CDBR-4220B 72600-R42200B
500 to
575 V
50 (37)
CDBR-5037B 72600-R5370B
150 (110)
CDBR-5110B 72600-R51100B
400 (300)
CDBR.5300B 72600-R53000B
