YASKAWA TOMPC71061753A YASKAWA AC Drive GA500 Installation and Operation Instruction 305
Model Terminal
Recommen
ded Gauge
AWG, kcmil
Applicable
Gauge
AWG, kcmil
Wire
Stripping
Length
*1
mm
Terminal Screw
Tightening
Torque
N∙m (in∙lb)
Size Shape
4012
R/L1, S/L2, T/L3 12 14 - 10 10 M4
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 14 14 - 12 10 M4
1.5 - 1.7
(13.5 - 15)
-, +1, +2 10 12 - 8 10 M4
1.5 - 1.7
(13.5 - 15)
B1, B2 14 14 - 12 10 M4
1.5 - 1.7
(13.5 - 15)
10
*2
14 - 10
*2
- M4
1.2 - 1.5
(10.6 - 13.3)
4018
R/L1, S/L2, T/L3 10 12 - 8 10 M4
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 10 12 - 8 10 M4
1.5 - 1.7
(13.5 - 15)
-, +1, +2 10 14 - 8 10 M4
1.5 - 1.7
(13.5 - 15)
B1, B2 14 14 - 12 10 M4
1.5 - 1.7
(13.5 - 15)
10
*2
14 - 6
*2
- M5
2.0 - 2.5
(17.7 - 22.1)
4023
R/L1, S/L2, T/L3 8 14 - 6 10 M4
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 10 14 - 8 10 M4
1.5 - 1.7
(13.5 - 15)
-, +1, +2 8 12 - 6 10 M4
1.5 - 1.7
(13.5 - 15)
B1, B2 12 14 - 10 10 M4
1.5 - 1.7
(13.5 - 15)
10
*2
10 - 6
*2
- M5
2.0 - 2.5
(17.7 - 22.1)
