7.3 Status Details
This section describes the STATUS field for main commands and the SUBSTATUS field for
sub-commands.
 STATUS Field
* With the MEM_RD command, only the settings for the STATUS (CMDRDY) is valid. Other
bits are not used.
Bit Name Description Value Setting
0 ALM Alarm status
0
No alarm
1
Alarm (fault)
1 WARNG Warning status
0
No warning
1
Warning
2 CMDRDY Command ready
0
Busy
1
Ready
3 BB OFF Baseblock OFF (OFF when output voltage is being
output from the Inverter or during baseblock.)
0
Baseblock ON
1
Baseblock OFF
4 PON Main power supply ON (OFF during undervoltage)
0
Main power supply OFF
1
Main power supply ON
5 RUNX Running
0
1
Running
6 0SP Zero speed
0
1
Zero speed
7 REV Reverse RUN
0
Forward RUN
1
Reverse RUN
8 RESET Fault reset signal input
0
1
Fault reset signal input
9 AGREE Speed agreement
0
1
Speed agreement
A INV_READY Inverter ready
0
1
Inverter ready
B OPE OPE fault
0
1
OPE fault
C UV_R Recovery after power loss or recovery after momen-
tary power loss
0
Recovery after power loss
1
Recovery after momentary
power loss
D REMOTE Local or Remote
0
Local
1
Remote (Transfer)
E − Not used.
0
1
F − Not used.
0
1
