Yealink CP960 Quick Start Guide

Packaging Contents
PoE Adapter
(Optional)
IP Phone
Note: The CPW90 helps you to expand the audio range of the IP phone. For more information, refer to Yealink CPW90 Quick Start Guide.
We recommend that you use the accessories provided or approved by Yealink. The use of unapproved third-party accessories may
result in reduced performance.
1. Connect the power and wired network.
Assembling the Phone
You can also connect to the wireless network after startup. Refer to Wireless Network Connection mentioned
below in Configuring Your Phone for more information.
Note: The IP phone should be used with Yealink original PoE adapter (54V/0.56A) only. The use of the third-party PoE adapter may cause
the damage to the phone.
The cable and wire should be replaced at once if its skin is broken.
1
Ethernet Cable
(7.5m CAT5E UTP cable)
CP Wired Expansion Mic CPE90
Quick Start Guide
(Optional)
CP Wireless Expansion Mic CPW90
(Optional)
Charging Cradle
0.3m
Micro USB Cable
Quick Start Guide
Wireless Expansion Mic
Power Cord
Ethernet Cable
(2m CAT5E FTP cable)
PSE
E
N
G
L
I
S
H
7.5m
2m
X 2
X 2

Yealink CP960 Specifications

General

Control type	Touch
Display type	LCD
Product type	IP conference phone
Voice codecs	CNG, G.722, G.722.1C, G.723, G.726, OPUS, VAD, iLBC
Product color	Stainless steel
Frequency range	2400 - 5000 Hz
Display diagonal	5 \
Display resolution	720 x 1280 pixels
Phonebook capacity	1000 entries
Ethernet interface type	Fast Ethernet
Microphone direction type	Omnidirectional
Supports expansion microphones	Yes
USB connector type	Micro-USB B
RJ-11 ports quantity	1
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	338 mm
Height	74 mm
Package depth	392 mm
Package width	405 mm
Package height	141 mm
