Yealink CP965 Recovery Guide

Recovery Mode on Yealink IP phones
5
Configuring the TFTP Server
This section shows how to configure a TFTP server for the windows system using the tftpd32 application.
You can download the tftpd32 application online: http://tftpd32.jounin.net/tftpd32_download.html. If there
is a TFTP server installed on your local system, you can skip this section and go to the next.
Procedures
1. Create a TFTP root directory on the local system.
2. Place resource files to this root directory.
3. Double click the tftpd32.exe to start the application.
4. Click the button to locate the TFTP root directory from the local system.
5. Select the local IP address from the Server interface drop-down menu.
Take a note of the server IP address (e.g., 10.2.11.123) which is used at the later stage.
Connecting the USB Flash Drive to the IP Phone
This section shows how to connect the USB flash drive to the IP phone. The USB flash drive should be
purchased separately.
This method is only applicable to MP54/MP56/MP58/VP59/SIP-T58A/T57W/T54W/T53W
/T53/T48U/T48S/T46U/T46S/T43U/T42U/T42S/T41S/CP920/CP960 IP phones.
Note
Procedures
1. Place resource files to the USB flash drive.
2. Connect the USB flash drive to the IP phone.
The file system of the USB flash drive should be FAT32.

Yealink CP965 Specifications

General

Control type	Touch
Display type	LCD
Product type	IP conference phone
Voice codecs	AGC, AJB, CNG, G.711a, G.711u, G.722, G.722.1C, G.723, G.726, G.729, G.729A, OPUS, PCMA, PLC, VAD, iLBC
Certification	CE, FCC, RoHS, REACH, ISO 9001, CCC
Product color	Black
Speaker power	5 W
Frequency range	100 - 20000 Hz
Built-in display	Yes
Display diagonal	5 \
Speaker diameter	56 mm
Bluetooth version	4.2
Display resolution	720 x 1280 pixels
Phonebook capacity	1000 entries
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	256-bit AES, HTTPS, MD5, WPA2, WPA3
Cable lock slot type	Kensington
Sound pressure level	94 dB
Recommended room size	Large room
Ethernet LAN data rates	10, 100 Mbit/s
Microphone pick-up range	6 m
Microphone direction type	Omnidirectional
Number of microphone arrays	1
Conference call ways quantity	10
USB version	2.0
USB connector type	USB Type-A, USB Type-C
USB ports quantity	2
Storage temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Master (outer) case width	392 mm
Master (outer) case height	410 mm
Master (outer) case length	552 mm
Master (outer) case weight	9020 g
Harmonized System (HS) code	85176990
Power consumption (max)	14 W
Power consumption (Power over Ethernet (PoE))	20 W

Weight and Dimensions

Depth	322 mm
Width	328 mm
Height	62 mm
Package depth	398 mm
Package width	384 mm
Package height	105 mm
