Yealink EXP20 User Manual

Yealink EXP20 User Guide
4
The EXP20 LCD expansion module applies to Yealink SIP-T29G/T27P IP phones. To
connect the EXP20 to the phone more easily, unplug the phone stand from the IP phone
before installation.
Note
To unplug the stand from the IP phone:
1. Unplug the power adapter and Ethernet cable from the IP phone.
2. Unplug the handset attached to the IP phone.
3. Turn the IP phone over and lay it on a non-slip, flat surface.
4. Unplug the stand from the IP phone.
To install the EXP20 LCD expansion module:
1. Turn the IP phone and the expansion module over and lay them on a flat, non-slip
surface.
2. Position the expansion module on the left of the IP phone.
3. Connect the EXP20 LCD expansion module and the IP phone using the supplied
connecting sheet and screws.
Up to six expansion modules can be connected to an IP phone.

Yealink EXP20 Specifications

General

Handset type	-
Product type	IP Phone
Product color	Black
Backlight display	Yes
Display resolution	160 x 320 pixels
Lines quantity	- lines
Phonebook capacity	- entries
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Number of handles included	- pc(s)
Certification	CE, RoHS
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	110 mm
Width	112 mm
Height	143 mm
