Yealink MVC640 Deployment Guide

| Basic Settings of Teams Room Systems | 62
2. If the WPP20 is first connected to the computer, you need to manually start the Yealink Wireless
Presentation Pod software from This PC in Windows 10 or from My Computer in Windows 7 and then
upgrade the WPP20.
• After starting the software, if it prompts that the firmware version is different from the host version,
you need to upgrade the WPP20 according to the prompts.
• For the WPP20 running old versions, after starting the software, you need to manually upgrade the
firmware on the software at the path > Version Update.
After the upgrade is successful, the WPP20 is ready for content sharing.
3. Do one of the following:
• On the WPP20, press the presentation button to share the full screen.
• On the WPP20, long press the presentation button for 3 seconds and then release the button. Select
the file or the window you want to share and then click Start Sharing.
• On the Yealink Wireless Presentation Pod software, click Contents Share and choose the file you
want to share, and then click Start Sharing.
The content you want to share is automatically projected to the display device.
Tip: Go to Yealink website for the latest version of the firmware.
Related tasks
Pairing the WPP20 with the MTouch
Ⅱ
Pairing the WPP20 with the MShare
Stopping Sharing Content via WPP20
Procedure
Do one of the following:
• On your computer, remove the WPP20.
• On the WPP20, press the presentation button.
• On the Yealink Wireless Presentation Pod software, click Stop Sharing.
Tip:
• You can tap Stop Present to stop sharing content when the device is idle.
• During a meeting, tap Stop Presenting to stop sharing content with the participants.
Adjusting the Lightness of MTouch/MTouch
Ⅱ
Procedure
1.
Tap .
2.
Tap and then drag the slider to adjust the lightness.

Yealink MVC640 Specifications

General

Bluetooth	Yes
Pan range	-100 - 100 °
Product type	Group video conferencing system
Product color	Black, Grey
Tilt angle range	-45 - 90 °
Number of persons	- person(s)
Signal-to-Noise Ratio (SNR)	63 dB
Processor family	Intel® Core™ i5
Computer system type	Mini PC
Operating system installed	Windows 10 IoT Enterprise
Internal memory	8000 MB
Storage media type	SSD
Total storage capacity	128 GB
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB connector type	USB Type-A, USB Type-B
Ethernet LAN (RJ-45) ports	1
HDMI output ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Telepresence	-
Display diagonal	8 \
Touchscreen type	Capacitive
Display resolution	1280 x 800 pixels
Megapixel	- MP
Camera type	Single camera
Digital zoom	3 x
Optical zoom	12 x
Focus adjustment	Auto
Image sensor size	- \
Focal length range	3.9 - 46.8 mm
Aperture range (F-F)	1.6 - 2.8
Camera shutter speed	1/60 - 1/10000 s
Minimum illumination	0.1 lx
Diagonal field of view	80 °
Vertical field of view	45 °
Horizontal field of view	73 °
Maximum frame rate	30 fps
Speaker power	10 W
Frequency range	100 - 20000 Hz
Microphone pick-up range	6 m
Output voltage Total Harmonic Distortion (THD)	1 %
Number of microphone arrays	3
Current	0.7 A
AC input voltage	100-240 V
DC input voltage	48 V
Power source type	AC
Harmonized System (HS) code	85176990

Weight and Dimensions

Weight	7600 g
