Yealink SIP-T46S Auto Provisioning Guide

Triggering the IP Phone to Perform Auto Provisioning
39
Triggering the IP Phone to Perform Auto
Provisioning
This chapter introduces the following methods to trigger the IP phone to perform auto
provisioning:
 Power On
 Repeatedly
 Weekly
 Flexible Auto Provision
 Auto Provision Now
 Multi-mode Mixed
 SIP NOTIFY Message
 Auto Provisioning via Activation Code
Power On
The IP phone performs the auto provisioning when the IP phone is powered on.
To activate the power on mode via a web user interface:
1. Click on Settings->Auto Provision.
When there is an active call on the IP phone during auto provisioning, the IP phone will detect
the call status every 30 seconds. If the call is released within 2 hours, the auto provisioning will be
performed as usual. Otherwise, the process will be ended due to timeout.

Yealink SIP-T46S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	10
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
Package depth	255 mm
Package width	274 mm
Package height	128 mm
