YOKOGAWA Daqstation DX1000N Series User Manual

24 IM 04L41B01-02E
Saving the Setup Data
In this example, we will save the setup data to a file named “SF2” on the CF card.
1 . Display the operation mode screen.
2 . Press MENU once to display the setting menu.
3 . Press the up arrow key twice to select Save/Load.
4 . Press the right arrow key once and down arrow key three times.
Select Save settings
5 . Press DISP/ENTER once.
6 . Press the Input soft key once.
7 . Enter “SF2” for the file name.
For the input procedure, see “Entering Values and Characters” on page 16.
8 . Press DISP/ENTER once. The message “Data are being saved to media”
appears, and the setup data is saved.
9 . Press ESC or MENU to return to the operation mode screen.
Operation complete.
Basic Operation
