5169032-UIM-C-0416
Johnson Controls Unitary Products 15
TABLE 8:
Electrical Data For Multi-source Power Supply: 208/230-1-60
Air
Handlers
Models
Heater
Models
Heater
Amps
@240V
Min. Circuit Ampacity
MOP
1
208V 230V 208V 230V
Circuit Circuit
1st
3
2nd 3rd
1st
3
2nd 3rd
1st
3
2nd 3rd
1st
3
2nd 3rd
24B 6HK16501306 52 22.9 37.6 – 24.9 41.5 – 25 40 – 25 45 –
30B
6HK16501306 52 22.9 37.6 – 24.9 41.5 – 25 40 – 25 45 –
6HK16501506 60 25.8 43.3 – 28.1 47.9 – 25 45 – 30 50 –
36B
6HK16501306 52 24.8 37.6 – 26.8 41.5 – 25 40 – 30 45 –
6HK16501506 60 27.7 43.3 – 30.0 47.9 – 30 45 – 30 50 –
6HK16501806 72 45.0 39.0 – 49.1 43.1 – 45 40 – 50 45 –
6HK16502006 80 49.3 43.3 – 53.9 47.9 – 50 45 – 60 50 –
36C
6HK16501306 52 24.8 37.6 – 26.8 41.5 – 25 40 – 30 45 –
6HK16501506 60 27.7 43.3 – 30.0 47.9 – 30 45 – 30 50 –
6HK16501806 72 45.0 39.0 – 49.1 43.1 – 45 40 – 50 45 –
6HK16502006 80 49.3 43.3 – 53.9 47.9 – 50 45 – 60 50 –
42C
6HK16501306 52 24.8 37.6 – 26.8 41.5 – 25 40 – 30 45 –
6HK16501506 60 27.7 43.3 – 30.0 47.9 – 30 45 – 30 50 –
6HK16501806 72 45.0 39.0 – 49.1 43.1 – 45 40 – 50 45 –
6HK16502006 80 49.3 43.3 – 53.9 47.9 – 50 45 – 60 50 –
48C
6HK16501306 52 27.3 37.6 – 29.3 41.5 – 30 40 – 30 45 –
6HK16501506 60 30.2 43.3 – 32.5 47.9 – 35 45 – 35 50 –
6HK16501806 72 47.5 39.0 – 51.6 43.1 – 50 40 – 60 45 –
6HK16502006 80 51.8 43.3 – 56.4 47.9 – 50 45 – 60 50 –
48D
6HK16501306 52 27.3 37.7 – 29.3 41.5 – 30 40 – 30 45 –
6HK16501506 60 30.1 43.3 – 32.5 47.9 – 35 45 – 35 50 –
6HK16501806 72 47.6 39.1 – 51.6 43.1 – 50 40 – 60 45 –
6HK16502006 80 51.8 43.3 – 56.4 47.9 – 50 45 – 60 50 –
6HK16502506 100 51.8 43.3 21.6 56.4 47.9 24.0 60 45 25 60 50 25
60C
6HK16501306 52 27.3 37.6 – 29.3 41.5 – 30 40 – 30 45 –
6HK16501506 60 30.2 43.3 – 32.5 47.9 – 35 45 – 35 50 –
6HK16501806 72 47.5 39.0 – 51.6 43.1 – 50 40 – 60 45 –
6HK16502006 80 51.8 43.3 – 56.4 47.9 – 60 45 – 60 50 –
60D
6HK16501306 52 27.3 37.6 – 29.3 41.5 – 30 40 – 30 45 –
6HK16501506 60 30.2 43.3 – 32.5 47.9 – 35 45 – 35 50 –
6HK16501806 72 47.5 39.0 – 51.6 43.1 – 50 40 – 60 45 –
6HK16502006 80 51.8 43.3 – 56.4 47.9 – 60 45 – 60 50 –
6HK16502506 100 51.8 43.3 21.7 56.4 47.9 24.0 60 45 25 60 50 25
1. MOP = Maximum Overcurrent Protection device; must be HACR type circuit breaker or time delay fuse. The 1st circuit includes blower motor amps. Refer to the
latest edition of the National Electric Code or in Canada the Canadian electrical Code and local codes to determine correct wire sizing.
