TABLE 5: BP060 COOLING CAPACITIES (5 TON)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1250
77 73.6 3.5 31.0 25.8 20.7 - - - 67.5 4.0 28.6 23.7 18.9 - - -
72 66.3 3.4 38.7 33.6 28.4 23.3 - - 61.5 3.9 36.5 31.7 26.9 22.0 - -
67 59.0 3.3 46.5 41.4 36.2 31.1 25.9 - 55.5 3.8 44.5 39.7 34.8 30.0 25.2 -
62 53.8 3.2 53.8 50.9 44.8 39.6 34.5 29.3 50.4 3.7 50.4 48.9 42.7 37.8 33.0 28.2
1500
77 76.2 3.5 33.5 27.8 22.1 - - - 70.2 4.0 31.3 25.8 20.3 - - -
72 68.6 3.4 41.8 36.1 30.5 24.8 - - 63.9 3.9 39.9 34.4 28.9 23.4 - -
67 61.0 3.3 50.2 44.5 38.8 33.1 27.4 - 57.7 3.8 48.4 42.9 37.4 31.9 26.4 -
62 55.7 3.2 55.7 53.7 47.9 42.3 36.6 30.9 52.3 3.7 52.3 51.4 45.9 40.4 34.9 29.4
57 50.2 3.2 50.2 50.2 47.0 41.3 35.7 30.0 48.6 3.7 48.6 48.6 45.7 40.2 34.7 29.2
1750
77 78.7 3.5 36.0 29.8 23.6 - - - 72.8 4.0 34.1 27.9 21.7 - - -
72 70.9 3.4 44.9 38.7 32.5 26.3 - - 66.3 3.9 43.2 37.1 30.9 24.7 - -
67 63.1 3.3 53.8 47.6 41.3 35.1 28.9 - 59.8 3.8 52.4 46.2 40.0 33.9 27.7 -
62 57.5 3.2 57.5 56.6 51.1 44.9 38.7 32.5 54.3 3.7 54.3 53.8 49.1 42.9 36.7 30.6
57 51.9 3.2 51.9 51.9 50.1 43.9 37.7 31.5 50.4 3.7 50.4 50.4 48.9 42.7 36.5 30.4
2000
77 81.3 3.5 38.5 31.8 25.1 - - - 75.4 4.0 36.8 30.0 23.2 - - -
72 73.2 3.4 48.0 41.2 34.5 27.7 - - 68.7 3.9 46.6 39.7 32.9 26.1 - -
67 65.1 3.3 57.4 50.6 43.9 37.2 30.4 - 62.0 3.8 56.3 49.5 42.7 35.8 29.0 -
62 59.4 3.2 59.4 59.4 54.3 47.5 40.8 34.1 56.2 3.7 56.2 56.2 52.2 45.4 38.6 31.8
57 53.5 3.2 53.5 53.5 53.2 46.5 39.7 33.0 52.2 3.7 52.2 52.2 52.1 45.2 38.4 31.6
2250
72 75.1 3.4 52.0 44.7 37.4 30.0 - - 70.0 3.9 50.2 42.8 35.4 28.0 - -
67 66.8 3.3 63.0 54.9 47.6 40.2 32.9 - 63.2 3.8 60.3 53.3 45.9 38.5 31.1 -
62 61.0 3.2 61.0 61.0 58.4 51.1 43.7 36.4 57.3 3.7 57.3 57.3 55.3 47.9 40.5 33.2
57 55.0 3.2 55.0 55.0 54.8 47.5 40.1 32.8 53.2 3.7 53.2 53.2 53.1 45.7 38.4 31.0
2500
72 77.0 3.5 56.1 48.2 40.2 32.3 - - 71.3 4.0 53.8 45.9 37.9 30.0 - -
67 68.5 3.3 68.5 59.2 51.3 43.3 35.4 - 64.4 3.9 64.4 57.1 49.2 41.2 33.3 -
62 62.5 3.3 62.5 62.5 62.5 54.6 46.6 38.7 58.4 3.8 58.4 58.4 58.4 50.4 42.5 34.6
57 56.4 3.3 56.4 56.4 56.4 48.4 40.5 32.6 54.2 3.8 54.2 54.2 54.2 46.3 38.3 30.4
95°F 105°F
1250
77 61.5 4.5 26.2 21.7 17.2 - - - 60.1 5.1 24.0 19.8 15.0 - - -
72 56.8 4.4 34.3 29.8 25.3 20.8 - - 54.9 5.0 33.0 28.2 23.4 18.6 - -
67 52.1 4.3 42.4 37.9 33.4 28.9 24.4 - 49.7 4.9 42.0 36.6 31.8 27.0 22.2 -
62 46.9 4.3 46.9 46.9 40.6 36.0 31.5 27.0 44.9 4.8 44.9 44.9 38.2 33.4 28.6 23.8
1500
77 64.2 4.5 29.2 23.8 18.5 - - - 62.2 5.0 27.5 21.9 16.3 - - -
72 59.3 4.4 37.9 32.6 27.3 22.0 - - 56.9 4.9 36.6 31.0 25.4 19.8 - -
67 54.3 4.3 46.7 41.4 36.1 30.8 25.5 - 51.5 4.9 45.7 40.1 34.5 28.9 23.3 -
62 49.0 4.2 49.0 49.0 43.8 38.5 33.2 27.8 46.5 4.8 46.5 46.5 41.5 35.9 30.3 24.7
57 47.0 4.2 47.0 47.0 44.4 39.1 33.7 28.4 45.6 4.8 45.6 45.6 42.1 36.5 30.9 25.3
1750
77 66.8 4.5 32.1 26.0 19.9 - - - 64.4 5.0 31.0 24.0 17.6 - - -
72 61.7 4.4 41.5 35.4 29.3 23.2 - - 58.8 4.9 40.2 33.8 27.5 21.1 - -
67 56.6 4.3 51.0 44.9 38.7 32.6 26.5 - 53.3 4.8 49.5 43.7 37.3 30.9 24.5 -
62 51.0 4.2 51.0 51.0 47.0 40.9 34.8 28.7 48.1 4.8 48.1 48.1 44.8 38.4 32.0 25.6
57 48.9 4.2 48.9 48.9 47.6 41.5 35.4 29.3 47.2 4.8 47.2 47.2 45.4 39.0 32.6 26.2
2000
77 69.5 4.5 35.1 28.2 21.3 - - - 66.6 5.0 34.5 26.1 18.9 - - -
72 64.2 4.4 45.2 38.2 31.3 24.4 - - 60.8 4.9 43.9 36.7 29.5 22.3 - -
67 58.9 4.2 55.2 48.3 41.4 34.5 27.6 - 55.0 4.8 53.2 47.2 40.0 32.8 25.6 -
62 53.1 4.2 53.1 53.1 50.2 43.3 36.4 29.5 49.8 4.7 49.8 49.8 48.1 40.9 33.7 26.5
57 50.9 4.2 50.9 50.9 50.9 44.0 37.1 30.1 48.8 4.7 48.8 48.8 48.8 41.6 34.4 27.2
2250
72 64.9 4.4 48.3 40.9 33.5 26.0 - - 61.5 4.9 46.9 39.2 31.5 23.8 - -
67 59.5 4.3 57.7 51.7 44.2 36.8 29.4 - 55.7 4.9 54.7 50.4 42.7 35.0 27.3 -
62 53.7 4.2 53.7 53.7 52.2 44.8 37.4 29.9 50.3 4.8 50.3 50.3 49.5 41.8 34.0 26.3
57 51.5 4.2 51.5 51.5 51.5 44.0 36.6 29.2 49.3 4.8 49.3 49.3 49.3 41.6 33.9 26.2
2500
72 65.6 4.5 51.5 43.6 35.6 27.7 - - 62.2 5.0 49.9 41.7 33.5 25.2 - -
67 60.2 4.4 60.2 55.0 47.1 39.1 31.2 - 56.3 4.9 56.3 53.7 45.4 37.2 29.0 -
62 54.3 4.3 54.3 54.3 54.3 46.3 38.4 30.4 50.9 4.9 50.9 50.9 50.9 42.6 34.4 26.2
57 52.0 4.3 52.0 52.0 52.0 44.1 36.1 28.2 49.9 4.8 49.9 49.9 49.9 41.6 33.4 25.2
