YORK INTERNATIONAL 19
FORM 160.49-O1
Control Center in SERVICE mode and press WARN-
ING RESET key. To reset any safety shutdown mes-
sage, press WARNING RESET key in SERVICE mode
with the COMPRESSOR switch in the STOP/RESET
position.
MANUAL OIL PUMP – This key is operational in any
mode. Press and release this key to run the oil pump.
Press and release the key again to stop the oil pump.
A 10-minute maximum is imposed on the running of
the oil pump (i.e., the oil pump will automatically shut
off after 10 minutes). If a longer running time is de-
sired, the key must be pressed again. The manual oil
pump feature is disabled during “START SEQUENCE
INITIATED” to allow for auto-zeroing of oil pressure
transducers.
DISPLAY DATA – This key is operational in any three
of the Control Center modes of operation (SERVICE,
LOCAL or REMOTE). It is used to display certain sys-
tem operating parameters that are relevant to trouble-
shooting the chiller system.
Press and the DISPLAY DATA key. The following mes-
sages will sequentially scroll on the display. Each mes-
sage will be displayed for 2 seconds.
No. 1
SAT TEMPS EVAP = XX.X°F, COND = XX.X°F
No. 2
DISCHARGE TEMP = XXX.X°F, OIL TEMP = XXX.X°F
No. 3
HOP = XX.X PSIG; LOP = XX.X PSIG
To hold each of the above messages, press and re-
lease the DISPLAY DATA key, then press and release
the DISPLAY HOLD key. Message No. 1 above will be
displayed and updated every 2 seconds until the DIS-
PLAY DATA key is pressed and released. Message
No. 2 is then displayed and updated every 2 seconds
until the DISPLAY DATA key is again pressed and re-
leased. Message No. 3 is then displayed and updated
every 2 seconds until either the DISPLAY DATA key is
again pressed and released (whereupon message No.
1 is displayed), or the DISPLAY HOLD key is pressed
and released (whereupon the DISPLAY DATA mes-
sages are removed from the display.)
HISTORY PRINT – This key is used to initiate a his-
tory print to the optional printer. Refer to Form 160.49-
N2 for operation of this key.
OPERATING MODES
The MicroComputer Control Center can be operated in
four different operating modes as follows:
SERVICE – enables all the Service keys except DIS-
PLAY DATA, MANUAL OIL PUMP, and HISTORY
PRINT, which are enabled in all modes. See “Service
Keys”, page 18.
LOCAL – This is the normal operating mode. The com-
pressor can be started and stopped from the Control
Center. Also, the Display and Setpoint parameters can
be displayed.
PROGRAM – Allows the operator to program the Set-
point parameters, and change operating modes.
REMOTE – In this mode, the Control Center will ac-
cept control signals from a remote device (i.e., Energy
Management System) or cycling input. The control sig-
nal inputs are:
1. Remote Start
2. Remote Stop
3. Remote LCWT Setpoint
4. Remove Current Limit Setpoint
NOTE: The compressor can be stopped by the COM-
PRESSOR switch, regardless of the operating
mode. The switch must be in RUN position to
enable REMOTE mode. The operator cannot
locally start the compressor using the COM-
PRESSOR switch when in the REMOTE mode.
To determine which operating mode the Control Center
is presently in, simply press the MODE key.
• If the Control Center is in LOCAL mode,
LOCAL OPERATING MODE IN EFFECT is displayed.
• If the Control Center is in REMOTE mode,
REMOTE OPERATING MODE IN EFFECT is displayed.
