York H5CE090 User Manual

036-21083-007-A-0404
4 Unitary Products Group
TABLE 4: ELECTRICAL DATA
MODEL (HCE) VOLTAGE CODE
COMPRESSOR CONDENSER FAN MOTOR
UNIT
AMPACITY
(AMPS)
MAX.
FUSE
SIZE
*
(AMPS)
POWER
SUPPLY
RLA LRA POWER SUPPLY HP QTY FLA
25 208/230-3-60 25.6 190 208/230-1-60 3/4 1 3.03 35.1 60
090 46 460-3-60 12.8 95 460-1-60 3/4 1 1.60 17.6 30
58 575-3-60 10.2 75 575-1-60 3/4 1 1.8 14.6 20
25 208/230-3-60 42.0 239 208/230-1-60 1/2 2 2.7 51.8 70
120 46 460-3-60 19.2 125 460-1-60 1/2 2 1.6 24.7 35
58 575-3-60 13.8 80
460-1-60
†
1/2 2 1.3 18.0 25
25 208/230-3-60 41.4 312 208/230-1-60 1/2 2 3.0 52.6 70
150 46 460-3-60 20.0 150 460-1-60 1/2 2 1.8 26.1 35
58 575-3-60 16.4 108 460-1-60† 1/2 2 1.8 21.3 30
*. Dual element.
†. Unit includes a 575 to 460-volt transformer.
TABLE 5: UNIT COOLING CAPACITIES AND POWER REQUIREMENTS
Model HCE
Suction Press. &
Corresponding Temp. @
Saturation
Temperature of Air on Condenser Coil,
°F
65 75 85 95 105 115
PSIG
°F MBH KW* MBH
KW
*
MBH KW* MBH KW* MBH KW* MBH KW*
090
61.6 35 90 6.1 88 6.7 81 7.2 77 7.9 74 8.6 68 9.5
68.5 40 101 6.3 96 6.8 91 7.4 87 8.1 82 8.9 77 9.7
76.0 45 110 6.5 109 7.0 101 7.6 95 8.4 90 9.1 85 10.0
84.0 50 120 6.6 115 7.2 109 7.8 104 8.6 99 9.4 93 10.3
120
61.6 35 123 7.7 117 8.4 112 9.1 106 9.9 100 10.8 95 11.8
68.5 40 134 8.0 128 8.6 122 9.3 116 10.1 110 11.0 104 12.1
76.0 45 145 8.2 139 8.8 132 9.5 126 10.4 120 11.3 113 12.3
84.0 50 156 8.4 150 9.1 143 9.8 136 10.6 129 11.5 123 12.5
150
61.6 35 140 9.4 133 10.4 127 11.3 119 12.6 112 13.8 105 15.1
68.5 40 151 9.6 144 10.6 137 11.5 129 12.8 122 14.1 114 15.4
76.0 45 165 9.9 156 10.9 148 11.8 140 13.1 132 14.4 124 15.8
84.0 50 178 10.2 169 11.2 159 12.1 151 13.4 142 14.8 134 16.1
*. Includes compressor and condenser fan motor(s).
