York HMH7 Series User Manual

Performance data - 2 ton
Cooling performance data - 2 ton
Table 9: Cooling performance data - 2 ton - air temperature (°F) entering outdoor unit
Outdoor unit model: HMH72B241S
ID CFM 600 800 1000
ID DB
(°F)
80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
Air
temp
(°F)
ID WB
(°F)
57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
T.C. 22.7 24.1 24.6 26.3 27.5 24.1 25.7 26.1 28.1 29.9 26.8 27.4 27.6 29.8 32.4
S.C. 22.2 19.6 16.7 16.8 12.7 24.1 22.3 18.8 18.4 14.2 26.3 25.0 20.9 20.0 15.7
55
kW 1.3 1.4 1.3 1.3 1.3 1.4 1.4 1.4 1.4 1.4 1.7 1.5 1.5 1.5 1.5
T.C. 21.8 23.0 23.3 25.1 26.1 23.2 24.5 24.9 26.7 28.4 25.5 26.1 26.5 28.4 30.7
S.C. 21.3 19.4 16.3 16.3 12.4 23.2 21.8 18.4 18.0 13.7 25.0 24.2 20.5 19.7 14.9
65
kW 1.5 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.9 1.7 1.7 1.7 1.7
T.C. 20.9 22.0 22.1 23.9 24.7 22.3 23.4 23.7 25.4 26.9 24.3 24.8 25.4 26.9 29.1
S.C. 20.4 19.0 15.9 15.8 12.0 22.3 21.1 18.0 17.5 13.1 23.8 23.3 20.0 19.3 14.1
75
kW 1.7 1.8 1.8 1.8 1.8 1.9 1.9 1.9 1.9 1.9 2.0 1.9 1.9 1.9 1.9
T.C. 20.0 20.9 20.8 22.7 23.3 21.4 22.2 22.5 24.1 25.4 23.0 23.6 24.2 25.4 27.4
S.C. 19.6 18.7 15.5 15.2 11.6 21.4 20.5 17.4 17.0 12.5 22.5 22.3 19.4 18.8 13.4
85
kW 2.0 2.0 2.0 2.0 2.0 2.1 2.1 2.1 2.1 2.1 2.2 2.2 2.2 2.2 2.2
T.C. 19.2 19.9 19.5 21.5 21.9 20.4 21.1 21.3 22.7 23.9 21.7 22.3 23.1 24.0 25.8
S.C. 18.7 18.2 14.9 14.7 11.2 20.4 19.8 16.9 16.5 11.9 21.3 21.4 18.9 18.3 12.6
95
kW 2.2 2.2 2.2 2.3 2.3 2.3 2.3 2.3 2.3 2.4 2.4 2.4 2.4 2.4 2.4
T.C. 18.3 18.8 18.3 20.2 20.5 19.5 19.9 20.1 21.4 22.3 20.5 21.0 21.9 22.5 24.1
S.C. 17.8 17.8 14.3 14.1 10.7 19.5 19.1 16.3 15.9 11.3 20.0 20.4 18.3 17.7 11.8
105
kW 2.4 2.4 2.4 2.5 2.5 2.5 2.5 2.5 2.6 2.6 2.6 2.6 2.6 2.7 2.7
T.C. 17.4 17.7 17.0 19.0 19.1 18.5 18.8 18.9 20.1 20.8 19.2 19.8 20.8 21.1 22.5
S.C. 17.0 17.2 13.7 13.4 10.2 18.5 18.3 15.7 15.2 10.6 18.8 19.4 17.6 17.1 11.0
115
kW 2.6 2.6 2.6 2.7 2.8 2.7 2.7 2.7 2.8 2.8 2.8 2.8 2.8 2.9 2.9
Note:
• All capacities include indoor fan heat. kW values are for the system (outdoor + indoor).
Heating performance data - 2 ton
Table 10: Heating performance data - 2 ton - air temperature (°F) entering outdoor unit
Outdoor unit model: HMH72B241S
ID CFMAir temperature (°F)
600 800 1000
Entering
outdoor unit
Entering
indoor coil
MBH COP kW MBH COP kW MBH COP kW
60 24.6 3.61 2.00 26.7 3.89 2.01 28.7 4.17 2.02
70 22.8 3.31 2.02 24.2 3.61 1.96 25.6 3.94 1.90
60
80 24.2 2.87 2.47 27.4 3.34 2.40 30.5 3.83 2.34
60 22.6 3.16 2.10 24.1 3.43 2.06 25.6 3.72 2.01
70 20.9 2.91 2.10 22.1 3.14 2.06 23.2 3.38 2.01
47
80 22.1 2.55 2.54 24.8 2.92 2.49 27.4 3.30 2.43
60 21.5 2.93 2.15 22.7 3.20 2.08 23.9 3.48 2.01
70 19.8 2.71 2.15 20.9 2.91 2.11 22.0 3.11 2.07
40
80 20.9 2.38 2.58 23.4 2.70 2.53 25.8 3.04 2.48
60 19.9 2.63 2.22 20.7 2.87 2.11 21.4 3.14 2.00
70 18.4 2.44 2.21 19.3 2.59 2.18 20.2 2.74 2.16
30
80 19.3 2.15 2.63 21.3 2.41 2.60 23.4 2.68 2.56
60 17.9 2.26 2.32 18.1 2.46 2.16 18.3 2.68 2.00
70 16.4 2.10 2.29 17.2 2.21 2.28 17.9 2.31 2.27
17
80 17.2 1.86 2.71 18.7 2.05 2.68 20.3 2.24 2.65
