York HMH7 Series User Manual

Performance data - 5 ton
Cooling performance data - 5 ton
Table 15: Cooling performance data - 5 ton - air temperature (°F) entering outdoor unit
Outdoor unit model: HMH72B601S
ID CFM 1500 1750 2000
ID DB
(°F)
80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
Air
temp
(°F)
ID WB
(°F)
57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
T.C. 55.2 60.6 60.4 64.4 67.7 56.8 61.7 61.7 65.2 68.2 59.1 63.3 63.7 66.4 69.0
S.C. 53.7 47.1 41.2 39.8 32.6 55.8 49.0 42.6 41.0 33.5 59.1 51.9 44.8 42.8 34.8
55
kW 4.39 4.41 4.42 4.47 4.50 4.47 4.51 4.50 4.55 4.58 4.58 4.66 4.63 4.68 4.70
T.C. 53.0 57.8 57.5 61.5 64.7 54.6 58.9 58.7 62.3 65.2 56.9 60.5 60.5 63.5 66.0
S.C. 52.7 46.6 40.3 39.1 32.1 54.3 48.7 41.9 40.4 32.9 56.9 51.7 44.3 42.3 34.1
65
kW 4.85 4.88 4.88 4.96 5.01 4.93 4.98 4.97 5.05 5.10 5.05 5.14 5.11 5.18 5.23
T.C. 50.8 55.1 54.6 58.6 61.7 52.4 56.1 55.7 59.4 62.2 54.6 57.6 57.3 60.5 62.9
S.C. 50.8 46.0 39.4 38.2 31.5 52.4 48.2 41.1 39.6 32.2 54.6 51.4 43.6 41.7 33.3
75
kW 5.32 5.35 5.35 5.45 5.52 5.40 5.46 5.45 5.55 5.61 5.52 5.62 5.59 5.69 5.76
T.C. 48.6 52.3 51.7 55.7 58.8 50.2 53.3 52.6 56.4 59.2 52.4 54.8 54.1 57.5 59.8
S.C. 48.6 45.2 38.3 37.3 30.8 50.2 47.5 40.1 38.7 31.5 52.4 50.8 42.7 40.9 32.5
85
kW 5.78 5.82 5.81 5.94 6.02 5.86 5.93 5.92 6.04 6.13 5.99 6.10 6.07 6.20 6.29
T.C. 46.4 49.5 48.7 52.8 55.8 48.0 50.5 49.6 53.5 56.2 50.2 52.0 50.9 54.5 56.7
S.C. 46.4 44.3 37.1 36.2 30.0 48.0 46.6 38.9 37.7 30.6 50.2 50.1 41.7 40.0 31.5
95
kW 6.24 6.28 6.28 6.44 6.53 6.33 6.40 6.39 6.54 6.64 6.46 6.58 6.55 6.70 6.81
T.C. 43.2 45.0 44.3 48.5 49.5 44.5 45.0 44.5 48.1 49.1 46.6 45.0 44.9 47.5 48.5
S.C. 43.2 41.9 35.4 34.4 28.2 44.5 43.1 37.0 39.7 36.3 46.6 45.0 39.5 47.5 48.5
105
kW 6.44 6.64 6.73 6.74 6.50 6.46 6.67 6.76 6.73 6.29 6.50 6.72 6.79 6.72 5.97
T.C. 34.6 33.9 33.7 37.2 37.5 35.4 34.1 33.9 37.1 37.2 36.6 34.5 34.1 36.8 36.8
S.C. 34.6 33.9 30.7 30.1 21.8 35.4 34.1 32.1 32.8 27.8 36.6 34.5 34.1 36.8 36.8
115
kW 5.38 5 5.32 5.46 5.32 5.44 5.47 5.42 5.51 5.13 5.55 5.50 5.57 5.59 4.85
Note:
• All capacities include indoor fan heat. kW values are for the system (outdoor + indoor).
• Drive output is limited in the shaded area. Performance may vary and interpolation is not
permissable.
Heating performance data - 5 ton
Table 16: Heating performance data - 5 ton - air temperature (°F) entering outdoor unit
Outdoor unit model: HMH72B601S
ID CFMAir temperature (°F)
1500 1750 2000
Entering
outdoor unit
Entering
indoor coil
MBH COP kW MBH COP kW MBH COP kW
60 62.4 3.69 4.95 63.1 3.80 4.87 63.9 3.91 4.79
70 59.6 3.29 5.30 60.8 3.41 5.23 64.0 3.64 5.16
60
80 58.6 3.02 5.69 61.4 3.18 5.65 64.2 3.35 5.62
60 54.9 3.41 4.72 55.8 3.51 4.67 56.8 3.61 4.61
70 52.1 3.04 5.02 53.2 3.13 4.98 54.3 3.22 4.94
47
80 50.4 2.76 5.36 53.2 2.91 5.36 56.0 3.06 5.36
60 50.9 3.25 4.59 51.9 3.34 4.55 52.9 3.43 4.52
70 48.1 2.89 4.87 49.1 2.97 4.85 52.2 3.18 4.82
40
80 46.0 2.60 5.19 48.8 2.75 5.20 51.5 2.89 5.22
60 45.1 3.00 4.40 46.3 3.09 4.39 47.5 3.18 4.38
70 42.4 2.67 4.66 43.3 2.72 4.65 46.4 2.92 4.65
30
80 39.7 2.35 4.94 42.5 2.50 4.98 45.2 2.64 5.02
YORK Technical Guide: HMH7 Series - 17 SEER Horizontal Discharge Modulating Heat Pump20
