5803641-JIM-B-0620
Johnson Controls Ducted Systems 9
Figure 8: JA3 thru A4ZJ Physical Dimensions
Ø 25.31
59.00
15.51
29.75
59
LEFT
11 3/8
21 3/16
89
27 5/16
4 3/16
FRONT
See detail A for gas inlet
A
See detail B for drain location
B
C
D
E
F
29.52
