York LEU360 User Manual

550.13-TG2Y (799)
6 Unitary Products Group
NOTE:
Temperature Water Drop (°F) = (2 x MBH)/GPM
TABLE 4: 2LP* MOTOR OVERLOAD ELEMENTS
VOLTAGE MOTOR HP KIT #
200 V
OLTS
230 V
OLTS
460 V
OLTS
10 HP Motor
2MP04701600
2MP04701400
2MP04701300
200 V
OLTS
230 V
OLTS
460 V
OLTS
15 HP Motor
2MP04701500
2MP04701700
2MP04701200
TABLE 5: 2LP* MOTOR STARTERS
MOTOR HP @ VOLTAGE KIT NUMBER
10HP motor @ 200 volts
or
15 HP motor @ 200 or 230 volts
2MS04700100
(60 AMP)
10HP motor @ 230 or 460 volts
or
15 HP motor @ 460 volts
2MS04700200
(30 AMP)
DO NOT OPERATE THE SUPPLY AIR BLOWER
MOTOR ABOVE ITS NOMINAL HP RATING
WHEN A UNIT IS EQUIPPED WITH A HOT
WATER COIL ACCESSORY. DO NOT USE
STEAM IN HOT WATER Coils.
DO NOT OPERATE THE SUPPLY AIR BLOWER
ABOVE ITS NOMINAL HP RATING WHEN A
UNIT IS EQUIPPED WITH A STEAM COIL
ACCESSORY.
ALTHOUGH THESE COILS ARE SUITABLE OF
A MUCH HIGHER PRESSURE, STEAM ABOVE
25 PSIG PROVIDES TOO MUCH HEAT THAT
COULD DAMAGE THE BLOWER MOTOR.
TABLE 6: HOT WATER COIL HEATING CAPACITIES
1
.
HOT WATER
COIL MODEL
UNIT
MODEL
GPM CFM
ENTERING WATER TEMPERATURE MINUS ENTRY AIR TEMPERATURE, °F.
70 90 110 130 150
1HW0406
LEU360 50
8,000 236 304 372 440 508
10,000 265 341 416 492 568
12,000 291 374 457 540 623
14,000 315 405 495 585 675
1HW0407
LEU480 75
12,800 348 447 547 646 746
16,000 389 500 611 722 833
19,200 425 547 668 790 911
LEU600 75
16,000 389 500 611 722 833
20,000 436 561 686 810 935
24,000 473 610 746 882 1,019
1.
These capacities do not include any blower motor heat.
