Assemble tools: Flat blade screwdriver, wire cutters and wire
strippers.
Carefully unpack the thermostat. Save the screws, any brack-
ets, and instructions.
Make sure your Heater/Air Conditioner is working properly
before beginning installation of the thermostat.
Turn off the power to the Heating/Air Conditioning system at
the main fuse panel. Most residential systems have a separate
breaker for disconnecting power to the furnace.
To install the thermostat properly, please follow these step by
step instructions. If you are unsure about any of these steps,
call a qualified technician for assistance.
