York PCG6 24 Series User Manual

5219967-UTG-A-0716
6 Johnson Controls Unitary Products
PHYSICAL DATA
NOMINAL TONNAGE
MODELS
PCG6A24 PCG6A30 PCG6B36 PCG6B42 PCG6B48 PCG6B60
2.0 2.5 3.0 3.5 4.0 5.0
AHRI Cooling Performance
Gross Capacity @ AHRI A point (MBH) 24.6 30.7 36.5 43.3 49.1 60.0
AHRI net capacity (MBH) 24.0 30.0 36.0 42.5 48.0 58.0
EER 12.5 12.5 12.5 12.5 12.5 12.0
SEER 16.0 16.0 16.0 16.0 16.0 16.0
Nominal CFM 800 1000 1200 1400 1600 2000
System power (KW) 2.0 2.4 3.0 3.4 3.6 4.6
Refrigerant type R410A R410A R410A R410A R410A R410A
Refrigerant charge (lb-oz) 6-8 8-2 11-8 11-2 14-8 14-10
AHRI Gas Heat Performance
Heating model 50 75 50 75 65 100 65 100 65 100 125 65 100 125
Heat input - High Fire (KBtu) 50 75 50 75 65 100 65 100 65 100 125 65 100 125
Heat output - High Fire (KBtu) 40 60 40 60 52 80 52 80 52 80 101 52 80 101
Heat input - Low Fire (KBtu) 32 49 32 49 42 65 42 65 42 65 81 42 65 81
Heat output - Low Fire (KBtu) 26 39 26 39 34 53 34 53 34 53 66 34 53 66
AFUE% 81.0 81.0 81.0 81.0 81.0 81.0 81.0 81.0 81.0 81.0 81.0 81.0 81.0 81.0
No. burners 2 3 2 3 2 3 2 3 2 3 4 2 3 4
No. stages 2 2 2 2 2 2 2 2 2 2 2 2 2 2
Temperature Rise Range - High Fire (°F) 40-70 40-70 40-70 40-70 40-70 40-70
Temperature Rise Range - Low Fire (°F) 20-50 20-50 25-55 25-55 25-55 25-55
Max. Static Pressure w.c. 0.5 0.5 0.5 0.5 0.5 0.5
Max. Outlet Air Temp. (°F) 180 180 180 180 180 180
Gas piping connection (in.) 1/2 1/2 1/2 1/2 1/2 1/2
Dimensions (inches)
Length 51-1/4 51-1/4 51-1/4 51-1/4 51-1/4 51-1/4
Width 35-3/4 35-3/4 45-3/4 45-3/4 45-3/4 45-3/4
Height 47 47 49 49 53 55
Compressor
Type Scroll Scroll Scroll Scroll Scroll Scroll
Condenser Coil Data
Face area (Sq. Ft.) 15.1 15.1 19.5 19.5 23.8 25.9
Rows 1 2 2 2 2 2
Fins per inch 22 22 22 22 22 22
Tube diameter 3/8 3/8 3/8 3/8 3/8 3/8
Circuitry Type Interlaced Interlaced Interlaced Interlaced Interlaced Interlaced
Evaporator Coil Data
Face area (Sq. Ft.) 4.6 4.6 6.3 6.3 6.3 6.3
Rows 3 3 3 3 3 4
Fins per inch 16 16 16 16 16 16
Tube diameter 3/8 3/8 3/8 3/8 3/8 3/8
Circuitry Type Interlaced Interlaced Interlaced Interlaced Interlaced Interlaced
Refrigerant control TXV TXV TXV TXV TXV TXV
Condenser Fan Data
Fan diameter (Inch) 24 24 26 26 26 26
Type Prop Prop Prop Prop Prop Prop
Drive type Direct Direct Direct Direct Direct Direct
No. speeds 1 1 1 1 1 1
Motor HP each 1/10 1/8 1/3 1/3 1/3 1/3
RPM 850 850 850 850 850 850
Nominal total CFM 2400 2400 3200 3200 3200 3200
Direct Drive Evaporator Fan Data
Fan Size (Inch) 11 x 8 11 x 8 11 x 10 11 x 10 11 x 10 11 x 10
Type Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal
Motor HP each 1/3 1/2 1/3 1/2 1/2 3/4 3/4 3/4 1
RPM 1200 Max 1200 Max 1200 Max 1200 Max 1200 Max 1200 Max
Frame size 48 48 48 48 48 48
Filters
Quantity - Size
Field-supplied external filters must be sized so as not to exceed 300 fpm air velocity through disposable
filters. For internal filter use, a filter rack kit is available. Consult the instructions supplied with that kit for
replacement filter sizes. Filter sizes: A=20x20, B=20x30.
