York PCG6 24 Series User Manual

5219967-UTG-A-0716
Johnson Controls Unitary Products 9
COOLING PERFORMANCE DATA - 3 TON (LOW SPEED)
PACKAGED UNIT MODEL NO. PCG6B36
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 600 800 1000
IDDB 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
IDWB 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
55 / 45
T.C. 44.8 53.4 53.8 59.3 63.3 48.0 53.1 53.5 57.4 60.9 51.2 52.9 53.1 55.6 58.6
S.C. 43.0 36.3 31.6 32.1 25.9 46.3 40.5 35.1 33.7 26.5 49.7 44.7 38.6 35.3 27.1
K.W. 3.11 2.90 2.90 2.86 2.82 3.05 2.86 2.86 2.82 2.79 2.98 2.82 2.82 2.79 2.76
65 / 55
T.C. 42.7 50.3 50.5 56.2 61.0 45.6 50.0 50.0 54.9 59.0 48.4 49.7 49.5 53.7 56.9
S.C. 40.9 34.8 29.8 30.5 24.6 43.9 38.7 33.2 32.6 25.6 47.0 42.7 36.5 34.8 26.7
K.W. 3.39 3.18 3.16 3.13 3.08 3.32 3.13 3.12 3.09 3.05 3.25 3.08 3.09 3.05 3.02
75 / 63
T.C. 40.6 47.2 47.3 53.1 58.7 43.2 46.8 46.6 52.4 57.0 45.7 46.4 45.9 51.8 55.3
S.C. 38.8 33.2 28.0 28.8 23.2 41.5 37.0 31.2 31.6 24.8 44.3 40.8 34.4 34.3 26.3
K.W. 3.66 3.45 3.42 3.39 3.34 3.59 3.40 3.39 3.36 3.31 3.52 3.35 3.35 3.32 3.28
85 / 69
T.C. 38.9 44.7 43.9 50.1 54.6 40.7 43.8 43.0 49.4 53.1 42.5 43.0 42.1 48.7 51.5
S.C. 36.6 31.7 26.5 27.3 21.5 38.9 35.6 29.6 30.3 22.9 41.2 39.6 32.7 33.3 24.4
K.W. 4.01 3.84 3.78 3.75 3.68 3.94 3.77 3.74 3.71 3.65 3.87 3.70 3.70 3.67 3.62
95 / 75
T.C. 37.1 42.2 40.6 47.2 50.5 38.2 40.8 39.5 46.4 49.1 39.3 39.5 38.4 45.6 47.8
S.C. 34.5 30.1 24.9 25.7 19.7 36.3 34.2 27.9 29.0 21.1 38.1 38.3 30.9 32.3 22.5
K.W. 4.35 4.23 4.13 4.11 4.03 4.28 4.14 4.09 4.06 3.99 4.22 4.05 4.05 4.01 3.96
105 / 83
T.C. 33.0 36.8 35.8 42.3 45.5 33.6 35.7 34.5 40.8 43.7 34.2 34.7 33.2 39.3 41.8
S.C. 29.9 27.1 22.0 23.3 17.5 31.5 30.3 25.0 26.3 18.7 33.2 33.6 28.0 29.3 19.9
K.W. 4.77 4.69 4.61 4.60 4.52 4.70 4.61 4.58 4.55 4.48 4.63 4.53 4.55 4.50 4.44
115 / 89
T.C. 29.0 31.5 31.2 37.6 40.7 29.2 30.7 29.7 35.4 38.4 29.3 30.0 28.1 33.2 36.0
S.C. 25.4 24.1 19.2 20.9 15.3 26.9 26.6 22.2 23.6 16.3 28.4 29.1 25.2 26.3 17.3
K.W. 5.19 5.14 5.08 5.07 4.99 5.11 5.07 5.06 5.02 4.95 5.04 5.00 5.03 4.97 4.91
125 / 95
T.C. 25.0 26.3 26.6 32.8 35.9 24.7 25.8 24.8 30.0 33.1 24.4 25.3 23.1 27.1 30.2
S.C. 20.9 21.2 16.4 18.6 13.1 22.2 22.8 19.4 21.0 13.9 23.6 24.5 22.4 23.4 14.7
K.W. 5.60 5.58 5.55 5.54 5.46 5.52 5.53 5.53 5.49 5.42 5.44 5.48 5.51 5.44 5.38
COOLING PERFORMANCE DATA - 3 TON (HIGH SPEED)
PACKAGED UNIT MODEL NO. PCG6B36
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1000 1200 1400
IDDB 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
IDWB 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
55 / 45
T.C. 45.0 53.3 52.6 55.8 57.3 47.0 52.5 51.1 55.3 58.2 47.7 50.3 48.4 53.5 57.8
S.C. 43.4 37.3 32.3 31.7 24.7 45.7 38.9 33.9 30.2 25.0 46.6 39.2 34.2 27.4 23.8
K.W. 3.40 3.44 3.43 3.44 3.41 2.89 2.90 2.89 2.90 2.86 2.91 2.91 2.89 2.90 2.87
65 / 55
T.C. 43.8 51.2 50.1 54.9 57.1 46.1 51.0 49.3 54.5 57.7 47.0 49.5 47.1 52.8 57.0
S.C. 43.0 36.6 31.1 30.9 24.3 44.8 39.0 33.0 31.3 25.0 45.3 40.2 33.7 30.5 24.3
K.W. 3.64 3.68 3.67 3.69 3.69 3.13 3.15 3.14 3.16 3.15 3.16 3.17 3.15 3.17 3.15
75 / 63
T.C. 42.7 49.1 47.7 54.0 56.9 45.2 49.6 47.4 53.7 57.2 46.3 48.8 45.7 52.0 56.2
S.C. 42.7 35.9 29.9 30.1 23.8 44.0 39.2 32.1 32.5 25.0 43.9 41.2 33.1 33.5 24.8
K.W. 3.88 3.93 3.92 3.95 3.97 3.38 3.41 3.40 3.43 3.43 3.42 3.43 3.42 3.45 3.43
85 / 69
T.C. 41.4 46.1 44.5 50.6 54.1 43.0 46.1 44.2 50.0 53.9 43.2 44.8 42.5 48.1 52.4
S.C. 40.5 34.1 28.1 28.7 22.3 41.6 37.3 30.4 31.0 23.9 41.4 39.1 31.3 32.0 24.1
K.W. 4.20 4.24 4.23 4.26 4.28 3.69 3.72 3.71 3.74 3.75 3.73 3.74 3.73 3.77 3.75
95 / 75
T.C. 40.2 43.0 41.4 47.2 51.3 40.8 42.6 40.9 46.4 50.6 40.1 40.8 39.2 44.3 48.7
S.C. 38.2 32.4 26.2 27.2 20.7 39.2 35.3 28.6 29.5 22.7 38.8 36.9 29.6 30.4 23.4
K.W. 4.52 4.55 4.54 4.58 4.60 4.01 4.02 4.02 4.06 4.07 4.04 4.04 4.04 4.08 4.08
105 / 83
T.C. 34.6 38.6 37.0 42.6 46.4 36.0 38.3 36.5 41.8 45.5 36.2 36.6 34.6 39.7 43.3
S.C. 33.2 30.1 23.9 25.1 18.3 34.9 32.7 26.3 27.4 20.2 35.2 34.0 27.4 28.4 20.7
K.W. 5.00 5.02 5.00 5.04 5.05 4.48 4.49 4.48 4.51 4.52 4.51 4.51 4.50 4.53 4.53
115 / 89
T.C. 29.1 34.3 32.8 38.1 41.7 31.4 34.1 32.1 37.3 40.6 32.3 32.5 30.2 35.2 38.1
S.C. 28.4 27.9 21.7 23.0 16.0 30.7 30.2 24.2 25.4 17.7 31.7 31.1 25.3 26.5 18.1
K.W. 5.47 5.47 5.45 5.48 5.50 4.95 4.95 4.93 4.95 4.96 4.97 4.97 4.95 4.97 4.97
125 / 95
T.C. 23.7 30.1 28.5 33.6 37.1 26.7 29.9 27.8 32.9 35.6 28.4 28.4 25.7 30.8 32.8
S.C. 23.5 25.7 19.5 20.8 13.7 26.5 27.6 22.0 23.3 15.2 28.2 28.2 23.2 24.5 15.4
K.W. 5.94 5.93 5.90 5.92 5.94 5.41 5.40 5.38 5.39 5.41 5.43 5.42 5.40 5.41 5.41
