York R-407C Optimized User Manual

104
YORK INTERNATIONAL
105
YORK INTERNATIONAL
FORM 201.19-EG4
CONTROL POWER SUPPLY (UNITS WITHOUT STANDARD CONTROL CIRCUIT TRANSFORMERS)
NO. OF
CONTROL MCA MAX DUAL NON-FUSED
COMPRESSORS
POWER (MAX LOAD ELEMENT DISCONNECT
SUPPLY CURRENT) FUSE SIZE SWITCH SIZE
2 115V-1Ø 20A 20A 30A
3 or 4
115V-1Ø 30A 30A 30A
(Non-CE 50/60Hz)
Electrical Data (continued)
OPTIONAL SINGLE-POINT POWER SUPPLY CONNECTION TO FACTORY CIRCUIT BREAKER –
2 COMPRESSOR UNITS (SEE FIG. 4)
(One Field Provided Power Supply Circuit to the chiller. Field Connections to Factory Provided Circuit Breaker in the ‘Options Panel’.
No Internal Branch Circuit Protection (Breakers) per Motor Control Center
10
.)
NOTE: Wye-Delta Compressor Start not available with this option.
See page 105 for Electrical Data footnotes.
FIELD SUPPLIED WIRING SYSTEM #1 SYSTEM #2
MODEL
VOLTS
MCA
1
FACTORY SUPPLIED BREAKER COMPRESSOR #1 FANS
11, 12
COMPRESSOR #2 FANS
11, 12
YCAS
RATING
2
WIRE RANGE
7
(LUGS) RLA XL-LRA QTY FLA(ea) LRA(ea) RLA XL-LRA QTY FLA(ea) LRA(ea)
380 228 250 # 6 - 350 89 681 3 4.8 23.0 89 681 3 4.8 23.0
0098EB 460 188 250 # 6 - 350 73 542 3 4.0 19.0 73 542 3 4.0 19.0
575 151 250 # 6 - 350 59 431 3 3.1 15.2 59 431 3 3.1 15.2
380 285 400 (2) 3/0 - 250 134 900 3 4.8 23.0 88 681 3 4.8 23.0
0118EB 460 236 400 (2) 3/0 - 250 111 719 3 4.0 19.0 73 542 3 4.0 19.0
575 189 250 # 6 - 350 90 574 3 3.1 15.2 59 431 3 3.1 15.2
380 275 400 (2) 3/0 - 250 122 900 4 4.8 23.0 84 681 4 4.8 23.0
0128EB 460 228 400 (2) 3/0 - 250 101 719 4 4.0 19.0 69 542 4 4.0 19.0
575 182 250 # 6 - 350 81 574 4 3.1 15.2 56 431 4 3.1 15.2
380 313 400 (2) 3/0 - 250 122 900 4 4.8 23.0 122 900 4 4.8 23.0
0138EB 460 259 400 (2) 3/0 - 250 101 719 4 4.0 19.0 101 719 4 4.0 19.0
575 206 250 # 6 - 350 81 574 4 3.1 15.2 81 574 4 3.1 15.2
380 313 400 (2) 3/0 - 250 122 900 4 4.8 23.0 122 900 4 4.8 23.0
0148EB 460 260 400 (2) 3/0 - 250 101 719 4 4.0 19.0 101 719 4 4.0 19.0
575 207 250 # 6 - 350 81 574 4 3.1 15.2 81 574 4 3.1 15.2
380 371 600 (2) 250 - 500 168 1093 4 4.8 23.0 122 900 4 4.8 23.0
0158EB 460 308 400 (2) 3/0 - 250 140 893 4 4.0 19.0 101 719 4 4.0 19.0
575 244 400 (2) 3/0 - 250 111 714 4 3.1 15.2 81 574 4 3.1 15.2
380 418 600 (2) 250 - 500 169 1093 4 4.8 23.0 169 1093 4 4.8 23.0
0178EB 460 347 400 (2) 3/0 - 250 140 893 4 4.0 19.0 140 893 4 4.0 19.0
575 275 400 (2) 3/0 - 250 111 714 4 3.1 15.2 111 714 4 3.1 15.2
380 451 600 (2) 250 - 500 198 1093 5 4.8 23.0 156 1093 5 4.8 23.0
0198EB 460 374 600 (2) 250 - 500 164 893 5 4.0 19.0 129 893 5 4.0 19.0
575 297 400 (2) 3/0 - 250 131 714 5 3.1 15.2 103 714 5 3.1 15.2
380 493 600 (2) 250 - 500 198 1093 5 4.8 23.0 198 1093 5 4.8 23.0
0208EB 460 408 600 (2) 250 - 500 164 893 5 4.0 19.0 164 893 5 4.0 19.0
575 325 400 (2) 3/0 - 250 131 714 5 3.1 15.2 131 714 5 3.1 15.2
CONTROL POWER SUPPLY (UNITS WITH STANDARD CONTROL CIRCUIT TRANSFORMERS)
NO. OF
CONTROL MCA RECOMMENDED NON-FUSED
COMPRESSORS
POWER (MAX LOAD DUAL ELEMENT DISCONNECT
SUPPLY CURRENT) FUSE SIZE SWITCH SIZE
200V - 60Hz 12.5A 30A –––
230V - 60Hz 10.9A 30A –––
2 380V - 60Hz 6.6A 15A –––
460V - 60Hz 5.4A 15A –––
575V - 60Hz 4.3A 15A –––
380V - 60Hz 9.9A 30A –––
3 or 4 460V - 60Hz 8.2A 15A –––
575V - 60Hz 6.5A 15A –––
