TABLE 23: ELECTRICAL DATA - BQ036-060 BELT DRIVE W/POWERED CONVENIENCE OUTLET
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
1. Minimum Circuit Ampacity.
Max
Fuse
2
/
Breaker
3
Size
(Amps)
2. Dual Element, Time Delay Type.
3. HACR type per NEC.
RLA LRA MCC FLA FLA FLA Model kW Stages Amps
036
(3.0)
208-3-60 11.9 85.0 16.7 1.7 5.2 10.0
None - - - 31.8 40
E05 4.0 1 11.1 45.7 50
E07 5.6 1 15.5 51.2 60
E10 8.0 1 22.2 59.5 60
E15 11.9 2 33.0 73.1 80
E20 15.9 2 44.1 86.9 90
230-3-60 11.9 85.0 16.7 1.7 5.2 10.0
None - - - 31.8 40
E05 5.3 1 13.3 47.7 50
E07 7.5 1 18.8 54.3 60
E10 10.6 1 26.6 63.6 70
E15 15.9 2 39.9 79.6 80
E20 21.2 2 53.2 95.5 100
460-3-60 5.9 42.0 8.2 1.0 2.6 5.0
None - - - 16.0 20
E07 6.8 1 8.5 26.2 30
E10 10.1 1 12.7 31.2 35
E15 13.6 2 17.1 36.4 40
E20 19.5 2 24.5 45.3 50
575-3-60 4.8 34.0 6.7 1.0 2.0 4.0
None - - - 12.8 15
E10 10.6 1 10.6 25.5 30
E15 15.9 1 16.0 31.9 35
E20 21.2 2 21.3 38.3 40
048
(4.0)
208-3-60 14.7 130.0 23.0 2.3 5.2 10.0
None - - - 35.9 50
E05 4.0 1 11.1 49.8 60
E07 5.6 1 15.5 55.3 60
E10 8.0 1 22.2 63.6 70
E15 11.9 2 33.0 77.2 80
E20 15.9 2 44.1 91.0 100
230-3-60 14.7 130.0 23.0 2.3 5.2 10.0
None - - - 35.9 50
E05 5.3 1 13.3 51.8 60
E07 7.5 1 18.8 58.4 60
E10 10.6 1 26.6 67.7 70
E15 15.9 2 39.9 83.7 90
E20 21.2 2 53.2 99.6 100
460-3-60 7.7 64.0 12.0 1.3 2.6 5.0
None - - - 18.5 25
E07 6.8 1 8.5 28.7 30
E10 10.1 1 12.7 33.7 35
E15 13.6 2 17.1 39.0 40
E20 19.5 2 24.5 47.8 50
575-3-60 6.4 52.0 10.0 1.3 2.0 4.0
None - - - 15.0 20
E10 10.6 1 10.6 27.8 30
E15 15.9 1 16.0 34.2 35
E20 21.2 2 21.3 40.5 45
060
(5.0)
208-3-60 19.3 137.0 27.0 2.3 5.2 10.0
None - - - 41.6 60
E05 4.0 1 11.1 55.5 70
E07 5.6 1 15.5 61.1 70
E10 8.0 1 22.2 69.4 80
E15 11.9 2 33.0 82.9 90
E20 15.9 2 44.1 96.8 100
E30 22.2 2 61.6 118.7 125
230-3-60 19.3 137.0 27.0 2.3 5.2 10.0
None - - - 41.6 60
E05 5.3 1 13.3 57.6 70
E07 7.5 1 18.8 64.2 70
E10 10.6 1 26.6 73.5 80
E15 15.9 2 39.9 89.4 90
E20 21.2 2 53.2 105.4 110
E30 29.6 2 74.3 130.6 150
460-3-60 10.0 62.0 14.0 1.3 2.6 5.0
None - - - 21.4 30
E07 6.8 1 8.5 31.6 35
E10 10.1 1 12.7 36.6 40
E15 13.6 2 17.1 41.8 45
E20 19.5 2 24.5 50.7 60
E30 28.8 2 36.1 64.7 70
575-3-60 7.9 50.0 11.0 1.3 2.0 4.0
None - - - 16.9 20
E10 10.6 1 10.6 29.6 30
E15 15.9 1 16.0 36.0 40
E20 21.2 2 21.3 42.4 45
E30 30.4 2 30.5 53.4 60
