TABLE 25: PHYSICAL DATA
MODELS
BQ
036 048 060
EVAPORATOR
BLOWER
Centrifugal Blower (Dia. x Wd. in.) 12 X 10 12 X 10 12 X 10
Fan Motor HP (Direct Drive) 1/2 3/4 1
Fan Motor HP (Belt Drive) 1 1/2 1 1/2 1 1/2
Fan Motor HP (Belt Drive High Static) 1 1/2 1 1/2 2
EVAPORATOR
COIL
Rows Deep 4 3 3
Fins Per Inch 16 15 15
Face Area (Sq. Ft.) 4.3 5.1 5.1
CONDENSER
FANS
Propeller Dia. (in.) 22 22 24
Fan Motor Hp 1/3 1/2 1/2
Nom. CFM 4300 4200 4500
CONDENSER
COILS
Rows Deep 1 1 1
Fins Per Inch 20 20 20
Face Area (Sq. Ft.) 17.1 17.1 17.1
COMPRESSOR
(Qty. Per Unit)
Reciprocating Type 1 1 1
AIR
FILTERS
Quantity Per Unit (15” X 20” X 1” or 2“) 2 2 2
Quantity Per Unit (14” X 25” X 1” or 2“) 1 1 1
Total Face Area (sq. ft.) 6.6 6.6 6.6
CHARGE
Refrigerant 22
(lbs./oz.)
7/12 9/2 8/4
TABLE 26: ELECTRIC HEAT CORRECTION
FACTORS
NOMINAL VOLTAGE VOLTAGE
kW CAP. MULTI-
PLIER
208
208 0.75
240
230 0.92
480
460 0.92
600
575 0.92
TABLE 27: VOLTAGE LIMITATIONS
1
1. Utilization Range “A” in accordance with ARI Standard
110.
POWER SUPPLY
VOLTAGE
MIN. MAX.
208/230-3-60
187 253
460-3-60
414 506
575-3-60
518 506
