CHARGING PROCEDURES:

1. Check the Factory Unit Charge listed on the unit nameplate to verify the refrigerant charge for the outdoor unit, the smallest matched indoor unit, and the 15 ft of

interconnecting lineset.

2. Verify the indoor metering device and additional charge required for the specific matched indoor unit in the system using the SYSTEM CHARGE FOR VARIOUS

MATCHED SYSTEMS table.

3. Add additional charge for the amount of interconnecting lineset tubing greater than 15 ft at the rate specified in the PHYSICAL AND ELECTRICAL DATA table.

4. For installations requiring additional charge, weigh in refrigerant for the specific matching indoor unit and actual lineset length.

5. After weighing in the charge adders for the matched indoor unit and lineset, verify the system operation against the temperatures and pressures in the Charging

Chart for the outdoor unit. Locate the Charging Charts on the outdoor unit and also in the Service Data Application Guide on

www.simplygettingthejobdone.com. Follow the Subcool or Superheat charging procedure in the Installation Manual according to the type of indoor metering device

in the system, and allow 10 min after each charge adjustment for the system operation to stabilize. Record the charge adjustment made to match the Charging

Chart.

6. Permanently stamp the unit nameplate with the TOTAL SYSTEM CHARGE defined as follows: TOTAL SYSTEM CHARGE = Base Charge (as shipped) + charge

adder for matched indoor unit + charge adder for actual lineset length + charge adjustments to match the Charging Chart.

SYSTEM CHARGE FOR VARIOUS MATCHED SYSTEMS

Outdoor Unit YCD18B22S YCD24B23S YCD30B22S YCD36B23S YCD42B23S YCD48B21S YCD60B22S

Required Orifice or TXV

1,2

1. For applications requiring a TXV, use S1-1TVM*** series kit.

2. Approved orifice(s) shipped with outdoor unit.

0.049 / BH1 0.057 / BH1 0.061 / BA1 0.070 / BA1 0.075 / BC1 0.077 / BC1 0.084 / BD1

Indoor Unit

3,4,5

3. Systems matched with furnaces or air handlers not equipped with blower-off delays may require 60-s time delay.

4. CF coils cannot be used in horizontal applications.

5. Charge adders shown above do not indicate that coils are rated for every application. See the performance data tables for actual performance for specified system

matches. Obtain certified system ratings from

www.ahridirectory.org.

Additional Charge (oz)

AP18B 0––– – – –

AP24B 30–– – – –

AP30B –72– – – –

AP36B –––0 – – –

AP36C ––22 – – –

AP37C –––5 – – –

AP42C –––– – – –

AP48C –––5 2 0 –

AP48D –––– 2 0 –

AP60(C,D) –––– – 2 –

AE18B 0––– – – –

AE24B 30–– – – –

AE30B 850– – – –

AE36(B,C) –720 – – –

AE42C –––5 2 – –

AE48(C,D) –––5 2 0 –

AE60C –––– 9 2 0

AE60D ––––29 oz TXV ONLY 22 oz TXV ONLY 20 oz TXV ONLY

AVC18B 0––– – – –

AVC24B 30–– – – –

AVC30B 850– – – –

AVC36(B,C) –720 – – –

AVC42C –––5 2 – –

AVC48(C,D) –––5 2 0 –

AVC60C –––– – 2 0

AVC60D ––––29 oz TXV ONLY 22 oz TXV ONLY 20 oz TXV ONLY

CF/CM/CU18(A,B) 0––– – – –

CF/CM/CU24(A,B) 30–– – – –

CF/CM/CU30(A,B,C) 850– – – –

CF/CM/CU36(A,B,C,D) 10 7 2 0 – – –

CF/CM/CU42(B,C,D) – 11 2 2 0 – –

CF/CM/CU48(C,D) –––5 2 0 –

CF/CM/CU60(C,D) –––– 9 2 0

CF/CM64D ––––29 oz TXV ONLY 22 oz TXV ONLY 20 oz TXV ONLY

Some of the combinations shown in this table require Advanced Main Air Circulating Fan indoor product. For approved coil only matches, see the

COOLING CAPACITY - Upflow, Downflow, and Horizontal Furnaces and Coils (Coil Only Ratings) table.
