York YCD42B23S User Manual

5752570-YTG-C-1020
78 Johnson Controls Ducted Systems
PERFORMANCE DATA - 2 TON
Multipliers for determining the performance with other indoor sections
Note: For dry bulb temperatures different than those listed (between 73°F to 87°F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
CONDENSER-ONLY DATA (OUTDOOR UNIT)
MODEL
SATURATED SUCTION
AT COMPRESSOR
Outdoor Ambient Temperature
55°F 65°F 75°F 85°F 95°F 105°F 115°F
T (°F) P (PSIG) MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW
YCD24B23S
35 107 23.6 1.27 22.3 1.47 21.0 1.67 19.6 1.85 18.2 2.03 16.8 2.20 15.4 2.37
40 118 26.0 1.24 24.6 1.45 23.2 1.66 21.7 1.85 20.2 2.04 18.7 2.22 17.1 2.41
45 130 28.6 1.21 27.1 1.44 25.6 1.65 24.0 1.85 22.4 2.04 20.7 2.24 19.0 2.43
50 142 31.3 1.19 29.7 1.42 28.1 1.64 26.4 1.85 24.7 2.05 22.9 2.26 21.1 2.46
55 156 34.2 1.17 32.5 1.41 30.8 1.64 29.0 1.86 27.1 2.06 25.2 2.27 23.3 2.48
Notes:
1. For Outdoor Unit (Condenser) performance only. Data does not include the effects of air handler power or heat.
2. Performance based on 15°F subcooling and 15°F superheat at the Outdoor Unit base valves.
a. Increase capacity by 1% for each 2°F increase in subcooling.
b. Decrease capacity by 1% for each 2°F decrease in subcooling.
3. Maximum recommended condensing temperature is 140°F.
COOLING PERFORMANCE DATA
OUTDOOR UNIT MODEL NO. YCD24B23S
INDOOR COIL MODEL NO. CF24AXA1
AIR TEMPERATURE
ENTERING
OUTDOOR UNIT (°F)
ID CFM 600 800 1000
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
55
T.C. 23.5 24.8 24.5 25.4 25.0 24.3 25.4 25.2 26.6 25.9 25.1 26.0 25.8 27.8 26.7
S.C. 22.4 18.9 16.6 15.5 11.2 23.5 20.2 17.5 16.7 11.9 24.5 21.4 18.5 18.0 12.5
kW 1.46 1.45 1.45 1.45 1.47 1.53 1.52 1.52 1.53 1.54 1.59 1.59 1.60 1.60 1.62
65
T.C. 22.8 24.4 24.0 25.4 24.9 24.0 25.2 24.7 26.5 25.8 25.1 26.1 25.4 27.7 26.8
S.C. 22.0 19.1 16.5 15.7 11.4 23.2 20.8 17.9 17.0 12.0 24.5 22.6 19.2 18.4 12.7
kW 1.61 1.60 1.60 1.60 1.61 1.68 1.67 1.67 1.67 1.68 1.75 1.74 1.75 1.75 1.76
75
T.C. 22.2 24.0 23.5 25.3 24.7 23.7 25.1 24.3 26.4 25.8 25.2 26.1 25.0 27.5 26.9
S.C. 21.6 19.2 16.4 15.9 11.6 23.0 21.5 18.2 17.4 12.2 24.5 23.7 20.0 18.8 12.8
kW 1.76 1.75 1.75 1.75 1.75 1.83 1.82 1.82 1.82 1.83 1.90 1.89 1.90 1.89 1.90
85
T.C. 21.3 23.9 22.2 24.2 25.0 22.9 23.7 23.2 25.3 26.0 24.4 23.6 24.2 26.5 26.9
S.C. 20.5 21.2 15.8 15.5 11.7 22.1 21.0 17.9 17.3 12.5 23.7 20.9 19.9 19.1 13.4
kW 1.93 2.01 1.93 1.93 1.94 2.01 2.01 2.00 2.01 2.01 2.09 2.00 2.08 2.09 2.09
95
T.C. 20.4 23.8 21.0 23.0 25.4 22.1 22.4 22.1 24.2 26.2 23.7 21.1 23.3 25.4 27.0
S.C. 19.5 23.1 15.2 15.2 11.8 21.3 20.6 17.5 17.2 12.9 23.0 18.1 19.8 19.3 13.9
kW 2.10 2.27 2.11 2.12 2.13 2.19 2.19 2.19 2.20 2.20 2.27 2.11 2.27 2.28 2.28
105
T.C. 19.2 20.6 19.1 21.5 23.5 21.0 20.5 20.2 22.6 24.2 22.8 20.5 21.3 23.8 24.9
S.C. 18.3 19.9 14.4 14.5 11.3 20.0 19.3 16.7 16.6 12.4 21.7 18.8 19.0 18.8 13.5
kW 2.31 2.39 2.31 2.33 2.35 2.40 2.40 2.39 2.42 2.43 2.49 2.41 2.48 2.50 2.51
115
T.C. 18.0 17.3 17.2 19.9 21.7 20.0 18.6 18.2 21.0 22.3 21.9 19.9 19.3 22.1 22.9
S.C. 17.0 16.6 13.6 13.8 10.7 18.7 18.0 15.9 16.1 11.9 20.4 19.4 18.1 18.3 13.2
kW 2.51 2.52 2.51 2.54 2.58 2.61 2.61 2.60 2.63 2.66 2.71 2.71 2.69 2.72 2.74
Note: All capacities include indoor fan heat. kW values are for the system (outdoor + indoor).
Green shaded cells are ACCA (TVA) conditions.
Blue shaded cells are AHRI conditions.
