SENSOR HARNESSES
FIG. 11 – HARNESS LAYOUT - YCUL0040 SHOWN (REF. TABLE 7)
075-50405-02
FIG. 12 – SENSOR HOUSING PART NUMBERS
12 Pin Plug
(025-28384-000)
45622-003b
6-PIN
(025-19670-000)
9-PIN
(025-28383-000)
15 Pin Plug
(025-28385-000)
12 Pin Plug
(025-21196-000)
Control & Power Panel
TABLE 7 – SENSOR HARNESSES - YCUL0016-YCUL0040 (SEE FIG. 11)
Board
Location
Cable
Length
Cable
No.
Wire
Color
Plug Pin
No.
Function
Harness Assembly
Part Number
MICRO
P6
192" 2
Black 4
Outside Air
Temperature
375-30434-406Red 7
Drain 1
MICRO
P4
140" 4
Red 5
System #1
Suction
Pressure
375-30434-401
White 10
Black 1
Drain 2
204"
Not
Shown
Red 7
System #1
Discharge
Pressure
375-30432-403
White 12
Black 8
Drain 9
MICRO
P5
Optional
Kit
115
Red 12
System #1 Suction
Temperature Sensor
371-37966-281Black 7
Drain 2
4
2
