271457-YTG-B-0908
24 Johnson Controls Unitary Products
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
OUTDOOR UNIT MODEL NO. YZB02411
INDOOR COIL MODEL NO. AHP24
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 600 800 1000
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 57 57 62 62 67 72
65
T.C. 21.7 24.5 23.6 27.4 29.9 24.0 25.4 24.8 28.4 30.8 26.4 26.3 26.0 29.5 31.7
S.C. 21.9 20.9 16.6 17.8 14.0 24.3 23.9 19.3 19.9 15.6 26.7 24.3 22.0 22.0 17.2
K.W. 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3
75
T.C. 20.9 23.1 22.3 25.5 28.0 23.1 24.2 23.4 26.6 28.9 25.3 25.4 24.5 27.6 29.9
S.C. 21.1 19.9 15.9 16.6 13.3 23.4 22.8 18.3 18.9 14.8 25.6 25.7 20.8 21.2 16.4
K.W. 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6
85
T.C. 20.2 21.7 21.1 23.6 26.1 22.2 23.1 22.0 24.7 27.1 24.3 24.5 23.0 25.8 28.1
S.C. 20.4 18.9 15.1 15.5 12.5 22.4 21.7 17.4 18.0 14.1 24.5 24.5 19.6 20.4 15.6
K.W. 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8
95
T.C. 19.5 20.2 19.8 21.7 24.1 21.4 21.9 20.6 22.8 25.2 23.2 23.6 21.4 23.9 26.3
S.C. 19.6 17.9 14.4 14.3 11.8 21.5 20.6 16.4 17.0 13.3 23.4 23.3 18.5 19.7 14.8
K.W. 2.0 2.0 2.1 2.0 2.0 2.0 2.0 2.1 2.0 2.0 2.0 2.0 2.1 2.0 2.0
105
T.C. 18.1 18.7 18.3 20.1 22.6 19.8 20.2 19.0 21.1 23.6 21.5 21.8 19.7 22.0 24.5
S.C. 18.2 17.0 13.7 13.7 11.2 19.9 19.2 15.7 16.2 12.8 21.7 21.4 17.7 18.8 14.3
K.W. 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4
115
T.C. 16.7 17.2 16.8 18.6 21.2 18.2 18.6 17.4 19.4 21.9 19.8 20.0 18.0 20.2 22.7
S.C. 16.8 16.1 13.0 13.0 10.7 18.4 17.8 15.0 15.4 12.2 20.0 19.5 17.0 17.9 13.8
K.W. 2.7 2.7 2.7 2.7 2.7 2.7 2.7 2.7 2.7 2.7 2.7 2.7 2.7 2.7 2.7
125
T.C. 15.3 15.7 15.3 17.1 19.7 16.7 17.0 15.8 17.7 20.3 18.1 18.3 16.3 18.4 20.9
S.C. 15.4 15.2 12.4 12.3 10.2 16.9 16.4 14.3 14.7 11.7 18.3 17.7 16.3 17.0 13.3
K.W. 3.0 3.1 3.1 3.1 3.0 3.0 3.1 3.1 3.1 3.0 3.0 3.1 3.1 3.1 3.0
NOTE: ALL CAPACITIES ARE NET (KBTUH) WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
MA08B FC/MC24B 1.00 1.00 1.00
MA08B FC/MC30B 1.00 1.00 1.00
MV12B FC/MC24B 1.03 1.02 0.96
MV12B FC/MC30B 1.03 1.02 0.96
AV24 – 1.03 1.02 0.96
F*FP030 – 1.00 1.00 1.00
– FC/MC/PC/UC24 1.00 1.00 1.00
– FC/MC/PC/UC30 1.00 1.00 1.00
– HC30 1.00 1.00 1.00
– HD24 0.98 1.06 1.00
Variable Speed
Furnace
Coil T.C. S.C. KW
PV8*A12 FC/MC/PC24A 1.00 0.96 1.03
PV9*A12 FC/MC/PC24A 1.00 0.96 1.07
PV8*A12 FC/MC/PC30A 1.00 0.96 1.03
PV9*A12 FC/MC/PC30A 1.00 0.96 1.07
Y*(8,L)C*A12 FC/MC/PC24A 1.02 1.05 0.92
Y*(8,L)C*B12 FC/MC/PC24B 1.02 1.05 0.91
Y*9C*B12 FC/MC/PC24B 1.02 1.05 0.93
Y*(8,L)C*A12 FC/MC/PC30A 1.02 1.05 0.92
Y*(8,L)C*B12 FC/MC/PC30B 1.02 1.05 0.91
Y*9C*B12 FC/MC/PC30B 1.02 1.05 0.93
Y*(8,L)C*A12 FC/MC/PC32A 1.02 1.04 0.93
Y*(8,L)C*A12 HC30 1.02 1.02 0.93
Y*(8,L)C*A12 HD24 1.04 1.06 0.93
Y*(8,L)C*B12 HD24 1.04 1.06 0.92
Y*9C*B12 HD24 1.04 1.06 0.93
Y*(8,L)C*A12 UC24A 1.04 1.05 0.93
Y*(8,L)C*B12 UC24B 1.04 1.06 0.92
Y*9C*B12 UC24B 1.03 1.05 0.93
Y*(8,L)C*A12 UC30A 1.04 1.05 0.93
Y*(8,L)C*B12 UC30B 1.04 1.06 0.92
Y*9C*B12 UC30B 1.03 1.05 0.93
G*9V*A12 FC/MC/PC24A 1.02 1.04 0.94
G*9V*B12 FC/MC/PC24B 1.02 1.05 0.93
G*9V*A12 FC/MC/PC30A 1.02 1.04 0.94
G*9V*B12 FC/MC/PC30B 1.02 1.05 0.93
G*9V*A12 FC/MC/PC32A 1.02 1.04 0.96
G*9V*A12 HC30 1.02 1.04 0.94
G*9V*A12 HD24 1.03 1.05 0.94
G*9V*B12 HD24 1.04 1.06 0.93
G*9V*A12 UC24A 1.03 1.04 0.94
G*9V*B12 UC24B 1.03 1.05 0.93
G*9V*A12 UC30A 1.03 1.04 0.94
G*9V*B12 UC30B 1.03 1.05 0.93
Variable Speed
Furnace
Coil T.C. S.C. KW
