10.4.2 Config menu “ADJUSTMENTS” functions list
To enter the CONFIG MENU it is necessary to push in the same time the right
side top and left side top buttons. Then roll until the ADJUSTMENTS item
appears on the hand set display. Push the ENTER button.
1) Opening Zapi Menu
CA0Z2A ZP1.00
24V 200A 00000
2) Press Top Left & Right Buttons to enter
CONFIG MENU
% ' %
' ' '
3) The Display will show: SET MODEL
CONFIG MENU
SET MODEL
4) Press ROLL UP button until ADJUSTMENTS
MENU appears
% ' '
' ' '
5) ADJUSTMENTS appears on the display
CONFIG MENU
ADJUSTMENTS
6) Press ENTER to go into the ADJUSTMENTS
MENU
' % '
' ' '
7) The display will show: SET BATTERY TYPE
BATTERY TYPE
24V
8) Press ROLL UP or ROLL DOWN button until
the desired parameter is reached
% ' '
% ' '
9) The desired parameter appears
TROTTLE 0 ZONE
3%
10) Press SET UP or SET DOWN button to modify
the adjustment
' ' %
' ' %
TROTTLE 0 ZONE
7%
11) Press OUT
' ' '
' % '
12) Press ENTER to confirm
' % '
' ' '
13) Repeat the same from 5 to 12 points for the
other adjustments
1) SET BATTERY TYPE
Selects the nominal battery voltage.
2) ADJUST BATTERY
Fine adjustment of the battery voltage measured by the controller.
3) THROTTLE 0 ZONE
Establishes a deadband in the accelerator input curve.
